| AD-A5A25A/911-91 |
SMA R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2
|
![SMA R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2]( "SMA R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2")
|
Standard |
In-Series |
SMA |
Jack (Female) |
SMA |
R/P Plug (Male) |
|
|
50 |
Straight |
None |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
18 |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
|
|
1.20 |
| AD-W2W25A-BH/9X-9X |
1.0mm Jack (Female) to 1.85mm Jack (Female) Bulkhead Adapter, DC-110GHz VSWR 1.35
|
![1.0mm Jack (Female) to 1.85mm Jack (Female) Bulkhead Adapter, DC-110GHz VSWR 1.35]( "1.0mm Jack (Female) to 1.85mm Jack (Female) Bulkhead Adapter, DC-110GHz VSWR 1.35")
|
Precision |
In-Series |
1.0mm |
Jack (Female) |
1.0mm |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
110 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.35 |
| AD-N2N25A-BH/H3-H3 |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Nickel |
Brass |
Nickel |
|
|
1.20 |
| AD-N2N25A-BH/93-93 |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Nickel |
Brass |
Nickel |
|
|
1.20 |
| AD-N1N25A-BH/H44-H4 |
N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2
|
![N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2]( "N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Plug (Male) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.20 |
| AD-N1N25A-BH/H44-H4 |
N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2
|
![N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2]( "N Plug (Male) to N Jack (Female) Bulkhead Adapter, DC-12 GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Plug (Male) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.20 |
| AD-D2D25A-BH/H4-H4 |
7/16 Jack (Female) to 7/16 Jack (Female) Bulkhead Adapter, DC-7.5 GHz VSWR 1.22
|
![7/16 Jack (Female) to 7/16 Jack (Female) Bulkhead Adapter, DC-7.5 GHz VSWR 1.22]( "7/16 Jack (Female) to 7/16 Jack (Female) Bulkhead Adapter, DC-7.5 GHz VSWR 1.22")
|
Standard |
In-Series |
7/16 |
Jack (Female) |
7/16 |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
7.5 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.22 |
| AD-N2N25A-BH/9X-9X |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-PCAQ1PCA25A-PT/99X-9X |
Precision SMA Snap-On Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Mount Adapter, DC-26.5 GHz VSWR 1.2
|
![Precision SMA Snap-On Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Mount Adapter, DC-26.5 GHz VSWR 1.2]( "Precision SMA Snap-On Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Mount Adapter, DC-26.5 GHz VSWR 1.2")
|
Precision |
Between Series |
Precision SMA Snap-On |
Plug (Male) |
Precision SMA |
Jack (Female) |
|
|
50 |
Straight |
2 Hole Flange |
Snap-On |
Threaded (Screw-lock) |
|
26.5 |
Beryllium Copper |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-B2B25A-BH/H4-H4 |
BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2
|
![BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2]( "BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2")
|
Standard |
In-Series |
BNC |
Jack (Female) |
BNC |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Bayonet |
Bayonet |
|
4.0 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.20 |
| AD-B2B25A-BH/93-93 |
BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2
|
![BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2]( "BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2")
|
Standard |
In-Series |
BNC |
Jack (Female) |
BNC |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Bayonet |
Bayonet |
|
4.0 |
Brass |
Nickel |
Brass |
Nickel |
|
|
1.20 |
| AD-PFD1PCA25A-PT/9X-9X |
SMP Full Detent Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Panel Mount Adapter, DC–27 GHz VSWR 1.20
|
![SMP Full Detent Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Panel Mount Adapter, DC–27 GHz VSWR 1.20]( "SMP Full Detent Plug (Male) to Precision SMA Jack (Female) 2-Hole Flange Panel Mount Adapter, DC–27 GHz VSWR 1.20")
|
Precision |
Between Series |
SMP |
Plug (Male) |
Precision SMA |
Jack (Female) |
|
|
50 |
Straight |
2 Hole Flange |
Snap-On |
Threaded (Screw-lock) |
|
27 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-N2N25A-BH/H4-H4 |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.20 |
| AD-B2B25A-BH/H3-H3 |
BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2
|
![BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2]( "BNC Jack (Female) to BNC Jack (Female) Bulkhead Adapter, DC-4GHz VSWR 1.2")
|
Standard |
In-Series |
BNC |
Jack (Female) |
BNC |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Bayonet |
Bayonet |
|
4.0 |
Brass |
Nickel |
Brass |
Nickel |
|
|
1.20 |
| AD-Q2Q25A-BH/9X-9X |
2.4mm Jack (Female) to 2.4mm Jack (Female) Bulkhead Adapter, DC-50GHz VSWR 1.2
|
![2.4mm Jack (Female) to 2.4mm Jack (Female) Bulkhead Adapter, DC-50GHz VSWR 1.2]( "2.4mm Jack (Female) to 2.4mm Jack (Female) Bulkhead Adapter, DC-50GHz VSWR 1.2")
|
Precision |
In-Series |
2.4mm |
Jack (Female) |
2.4mm |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead Hexagonal Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
50 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-N2N25A-BH/94-94 |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
|
|
1.20 |
| AD-N2N25B-BH/HX-HX |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-K2K25B-BH/9X-9X |
2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15
|
![2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15]( "2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15")
|
Precision |
In-Series |
2.92mm |
Jack (Female) |
2.92mm |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead Hexagonal Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
40 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.15 |
| AD-N2N25A-BH/HX-HX |
N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2
|
![N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2]( "N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2")
|
Standard |
In-Series |
N |
Jack (Female) |
N |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
12 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.20 |
| AD-K2K25A-BH/9X-9X |
2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15
|
![2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15]( "2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15")
|
Precision |
In-Series |
2.92mm |
Jack (Female) |
2.92mm |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead Hexagonal Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
40 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.15 |
| AD-Q2Q25B-PFM2/9X-9X |
2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15
|
![2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15]( "2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15")
|
Precision |
In-Series |
2.4mm |
Jack (Female) |
2.4mm |
Jack (Female) |
|
|
50 |
Straight |
4 Hole Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
50 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.15 |
| ADT-B2B1B25A/H4-144-H4 |
BNC Jack (Female) to BNC Plug (Male) to BNC Jack (Female) T-Adapter, DC-4GHz
|
![BNC Jack (Female) to BNC Plug (Male) to BNC Jack (Female) T-Adapter, DC-4GHz]( "BNC Jack (Female) to BNC Plug (Male) to BNC Jack (Female) T-Adapter, DC-4GHz")
|
Standard |
In-Series |
BNC |
Jack (Female) |
BNC |
Plug (Male) |
BNC |
Jack (Female) |
50 |
T-Adapter |
None |
Bayonet |
Bayonet |
Bayonet |
4.0 |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
Brass |
Copper-Tin-Zinc Alloy |
N/A |
| AD-Q2Q25A-PF/9X-9X |
2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15
|
![2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15]( "2.4mm Jack (Female) to 2.4mm Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-50GHz VSWR 1.15")
|
Precision |
In-Series |
2.4mm |
Jack (Female) |
2.4mm |
Jack (Female) |
|
|
50 |
Straight |
4 Hole Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
50 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.15 |
| AD-K2K25C-BH/9X-9X |
2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15
|
![2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15]( "2.92mm Jack (Female) to 2.92mm Jack (Female) Bulkhead Adapter, DC-40GHz VSWR 1.15")
|
Precision |
In-Series |
2.92mm |
Jack (Female) |
2.92mm |
Jack (Female) |
|
|
50 |
Straight |
Bulkhead Hexagonal Flange |
Threaded (Screw-lock) |
Threaded (Screw-lock) |
|
40 |
Stainless Steel |
Passivated |
Stainless Steel |
Passivated |
|
|
1.15 |
