Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-E1B25A/H3-H3	FME Plug (Male) to BNC Jack (Female) Adapter. DC-2.5GHz VSWR1.22	Standard	Between Series	FME	Plug (Male)	BNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Bayonet	2.5	Brass	Nickel	Brass	Nickel	1.22
AD-B1B25A/133-H3	BNC Plug (Male) to BNC Jack (Female) Adapter, DC-6GHz VSWR 1.2	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	50	Straight	None	Bayonet	Bayonet	6.0	Brass	Nickel	Brass	Nickel	1.20
AD-N2N25A-BH/HX-HX	N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2	Standard	In-Series	N	Jack (Female)	N	Jack (Female)	50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-B1B15A/133-133	BNC Plug (Male) to BNC Plug (Male) Adapter, DC-6 GHz VSWR 1.2	Standard	In-Series	BNC	Plug (Male)	BNC	Plug (Male)	50	Straight	None	Bayonet	Bayonet	6.0	Brass	Nickel	Brass	Nickel	1.20
AD-A2A75A/91-91	SMA Jack (Female) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-E1E15A/H4-H4	FME Plug (Male) to FME Plug (Male) Adapter, DC-2.5GHz VSWR 1.25	Standard	In-Series	FME	Plug (Male)	FME	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	2.5	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25
AD-A2A75B/91-91	SMA Jack (Female) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-N1N15A/1XX-1XX	N Plug (Male) to N Plug (Male) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Plug (Male)	N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-N1N25A/944-94	N Plug (Male) to N Jack (Female) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-N1N25A/HXX-HX	N Plug (Male) to N Jack (Female) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-E1B25A/14-94	FME Plug (Male) to BNC Jack (Female) Adapter. DC-2.5GHz VSWR1.22	Standard	Between Series	BNC	Jack (Female)	FME	Plug (Male)	50	Straight	None	Bayonet	Threaded (Screw-lock)	2.5	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.22
AD-A5A25A/111-11	SMA R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	R/P Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A75B/9X-9X	SMA Jack (Female) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-B1B25A/H33-H3	BNC Plug (Male) to BNC Jack (Female) Adapter, DC-6GHz VSWR 1.2	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Bayonet	Bayonet	6.0	Brass	Nickel	Brass	Nickel	1.30
AD-B2B25A/H3-H3	BNC Jack (Female) to BNC Jack (Female) Adapter, DC-6 GHz VSWR 1.2	Standard	In-Series	BNC	Jack (Female)	BNC	Jack (Female)	50	Straight	None	Bayonet	Bayonet	6.0	Brass	Nickel	Brass	Nickel	1.20
AD-B1B25A/H44-H4	BNC Plug (Male) to BNC Jack (Female) Adapter, DC-6GHz VSWR 1.2	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	50	Straight	None	Bayonet	Bayonet	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A2A75A/9X-9X	SMA Jack (Female) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-E1B25A/14-94	FME Plug (Male) to BNC Jack (Female) Adapter. DC-2.5GHz VSWR1.22	Standard	Between Series	FME	Plug (Male)	BNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Bayonet	2.5	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.22
AD-A5A75A/911-91	SMA R/P Plug (Male) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Jack (Female)	SMA	R/P Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-N1N25A/H33-H3	N Plug (Male) to N Jack (Female) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Nickel	Brass	Nickel	1.15
AD-N1N25A/933-93	N Plug (Male) to N Jack (Female) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Nickel	Brass	Nickel	1.15
AD-N1N15A/144-144	N Plug (Male) to N Plug (Male) Adapter, DC-11 GHz VSWR 1.15	Standard	In-Series	N	Plug (Male)	N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-N2N25A-BH/83-83	N Jack (Female) to N Jack (Female) Bulkhead Adapter, DC-12GHz VSWR 1.2	Standard	In-Series	N	Jack (Female)	N	Jack (Female)	50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Nickel	Brass	Nickel	1.20
AD-A5A55B/911-911	SMA R/P Plug (Male) to SMA R/P Plug (Male) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Plug (Male)	SMA	R/P Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20

RF Adapters
