Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-A2A25B-PF/91-91	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25A-PF/91-91	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-B2B25A-PF/H4-H4	BNC Jack (Female) to BNC Jack (Female) 4-Hole Panel Adapter, DC-4 GHz VSWR 1.20	Standard	In-Series	BNC	Jack (Female)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Bayonet	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A2A25A-PF/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25B-PF/911-91	SMA Plug (Male) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25B-PF/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25A-PF/H1-H1	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25B-PF/911-91	SMA Plug (Male) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25A-PF/H3-H3	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.15
AD-A2A25A-PF/9X-9X	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-A2A25A-PT/91-91	SMA Jack (Female) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25A-PT/9X-9X	SMA Jack (Female) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-A2A25B/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A25B/93-93	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.20
AD-A2A25B/91-91	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)		Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25A/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A25A/99-99	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A25A/94-94	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A2A25A/93-93	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.20
AD-A2A25A/91-91	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A25B-BH/9X-9X	SMA Jack (Female) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2A25A-BH/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A2A25A/9X-9X	SMA Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2A25A-BH/93-93	SMA Jack (Female) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.20
