Key Specifications
Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
7/16
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
LC
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
1.0
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
1.20
Description
7/16 Jack (Female) to LC Jack (Female) | Straight Design | Screw-Lock | Brass Body
The ROSNOL AD-D2LC25A/04-04 is designed for 50 Ω systems, supporting DC to 1 GHz with VSWR ≤1.20 and insertion loss ≤0.1 × √F (GHz) dB. Coupling uses screw-lock on both sides, ensuring secure engagement with ≥500 mating cycles. Rated for −65 °C to +165 °C, this adapter offers reliable performance for RF applications.Materials and plating: center contacts are brass with silver plating for optimal conductivity. Bodies are brass with copper-tin-zinc alloy plating; insulators are PTFE. This design ensures corrosion resistance and long-term durability.
ROSNOL delivers precision-engineered RF adapters for uncompromising performance in high-frequency and microwave applications. Manufactured under ISO 9001-certified processes, fully RoHS and REACH compliant, and offering cost-effective alternatives to leading brands. Customization for materials, plating, and mechanical design is available to meet specialized interconnect requirements.
