Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
SMA1E50-0141A/9QX	SMA Male Cable Connector for .141, DC- 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
N2CA50-G058A/H4	N Female Bulkhead Cable Connector, RG58, 6 GHz	Standard	50	Straight	6.0	1.15	N	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58
NM-SMA1C59-G316A/111	Non-Magnetic SMA Male RA Cable Connector for RG316, 6 GHz	Standard	50	Right Angle	6.0	1.35	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	RG-316
PCA1E50-0141A/111	Precision SMA Male Connector for .141, 27GHz	Precision	50	Straight	27	1.20	Precision SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
PCA1E50-0141A/9QQ	Precision SMA Male Connector for .141, 27GHz	Precision	50	Straight	27	1.20	Precision SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
SMA2EA50-0085A/91	SMA Female Bulkhead Cable Connector, RSR085, 18 GHz	Standard	50	Straight	18	1.25	SMA	Jack Female	Threaded (Screw-lock)	Crimped or Soldered	Soldered	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
PCA1E50-0141A/1XX	Precision SMA Male Connector for .141, 27GHz	Precision	50	Straight	27	1.20	Precision SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
MSMB1C79-G179A/911	Mini SMB Male RA Cable Connector for RG187, 2 GHz	Standard	75	Right Angle	2.0	1.22	SMB	Plug (Male)	Snap-On	Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-187
SMA1C59-G058A/111	SMA Male RA Cable Connector for RG58, 3 GHz	Standard	50	Right Angle	3.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	RG-58
SMA2EA50-0047A/9X	SMA Female Bulkhead Cable Connector, RSR047, 18 GHz	Standard	50	Straight	18	1.25	SMA	Jack Female	Threaded (Screw-lock)	Soldered	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Semi-Rigid .047 (RSR-047)
SMA2EA50-0047A/91	SMA Female Bulkhead Cable Connector, RSR047, 18 GHz	Standard	50	Straight	18	1.25	SMA	Jack Female	Threaded (Screw-lock)	Crimped or Soldered	Soldered	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .047 (RSR-047)
BNC1C50-R240A/133	BNC Male Cable Connector for LMR240, DC- 4GHz	Standard	50	Straight	4.0	1.20	BNC	Plug (Male)	Bayonet	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	LMR-240
TNC2CBF50-G316A/HX	TNC Female Cable Connector, 4 Hole, RG316, 11 GHz	Standard	50	Straight	11	1.15	TNC	Jack (Female)	Threaded (Screw-lock)	Crimped	Crimped	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	RG-316
SMA1C59-G058A/911	SMA Male RA Cable Connector for RG58, 3 GHz	Standard	50	Right Angle	3.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	RG-58
TNC2CBF50-G316A/9X	TNC Female Cable Connector, 4 Hole, RG316, 11 GHz	Standard	50	Straight	11	1.15	TNC	Jack (Female)	Threaded (Screw-lock)	Crimped	Crimped	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	RG-316
SMB2CA50-G316A/11	SMB Female Bulkhead Cable Connector, RG316, 4GHz	Standard	50	Straight	4.0	1.22	SMB	Jack (Female)	Snap-On	Crimped or Soldered	Crimped	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-316
TNC1D50-R400A/133	TNC Male Cable Connector for LMR400, 6 GHz	Standard	50	Straight	6.0	1.30	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	LMR-400
N1D50-R400A/144	N Male Cable Connector for LMR400, DC- 6GHz	Standard	50	Straight	6.0	1.30	N	Plug (Male)	Threaded (Screw-lock)	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
BNC1D50-R400A/144	BNC Male Cable Connector for LMR 400, DC- 4GHz	Standard	50	Straight	4.0	1.30	BNC	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
SMA1E50-0141A/9QQ	SMA Male Cable Connector for .141, DC- 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
716-1C50-EZR400A/144	7/16 Male Connector for LMR 400 cable, 7.5GHz	Standard	50	Straight	7.5	1.30	7/16	Plug (Male)	Threaded (Screw-lock)	Plug-in	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
716-2D50-R400A/H4	7/16 Female Connector for LMR 400 cable, 6GHz	Standard	50	Straight	6.0	1.30	7/16	Jack (FeFemale)	Threaded (Screw-lock)	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
N1C50-G316A/144	N Male Cable Connector for RG 316, DC- 6GHz	Standard	50	Straight	6.0	1.20	N	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-316
N2C50-G316A/H3	N Female Cable Connector for RG316, 6 GHz	Standard	50	Straight	6.0	1.22	N	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-316
