Precision TNC Male to Precision TNC Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.25, 50 Ω Impedance.
ROSNOL AD-PCT1PCT25A1/9XX-9X is a Precision TNC Plug (Male) to Precision TNC Jack (Female) straight RF adapter designed for 50 Ω systems operating from DC to 18 GHz. With VSWR ≤ 1.25, low insertion loss, and stable broadband performance, it is suitable for RF measurement, microwave communication, and precision interconnect applications.
The adapter utilizes beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating to ensure low contact resistance and reliable conductivity. The body and fastening nut are constructed from passivated stainless steel, while PTFE insulators and silicone rubber gaskets enhance dielectric stability and environmental durability. Key specifications include insulation resistance ≥ 5 GΩ, center contact resistance ≤ 1.5 mΩ, test voltage 1500 Vrms, and operating voltage 500 Vrms.
Featuring a screw-on coupling mechanism and durability exceeding 500 mating cycles, this adapter provides dependable RF connectivity and mechanical reliability. It is widely used in RF test systems, wireless infrastructure, aerospace electronics, microwave assemblies, and laboratory instrumentation.
