Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Connector 3 Series	Connector 3 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Connector 3 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	Connector 3 Body Material	Connector 3 Body Plating	VSWR, Max
AD-A2PCN25A/93-93	SMA Jack (Female) to Precision N Jack (Female) Adapter, DC-18GHz VSWR1.15	Precision	Between Series	SMA	Jack (Female)	Precision N	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Nickel	Brass	Nickel			1.15
AD-A5A75A/911-91	SMA R/P Plug (Male) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	R/P Plug (Male)	SMA	R/P Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-A2A75B/91-91	SMA Jack (Female) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	R/P Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-Q2PCN25A/9X-9X	2.4mm Jack (Female) to Precision N Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	2.4mm	Jack (Female)	Precision N	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
AD-A2PCN25A/91-9X	SMA Jack (Female) to Precision N Jack (Female) Adapter, DC-18GHz VSWR1.15	Precision	Between Series	SMA	Jack (Female)	Precision N	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Passivated			1.15
AD-A1PCN25A/9XX-9X	SMA Plug (Male) to Precision N Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	SMA	Plug (Male)	Precision N	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
AD-D2D25A-PF/G4-G4	7/16 Jack (Female) to 7/16 Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-7.5GHz VSWR 1.2	Standard	In-Series	7/16	Jack (Female)	7/16	Jack (Female)			50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		7.5	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			1.20
AD-A2M25A/91-91	SMA Jack (Female) to MCX Jack (Female) Adapter, DC-6.0GHz VSWR 1.20	Standard	Between Series	SMA	Jack (Female)	MCX	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Snap-On		6.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-A1M25A/911-91	SMA Plug (Male) to MCX Jack (Female) Adapter, DC-6GHz VSWR1.20	Standard	Between Series	SMA	Plug (Male)	MCX	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Snap-On		6.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-N1M25A-BH/944-91	N Plug (Male) to MCX Jack (Female) Bulkhead Adapter, DC-6GHz VSWR1.20	Standard	Between Series	N	Plug (Male)	MCX	Jack (Female)			50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)		6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-N2M25A-BH/94-91	N Jack (Female) to MCX Jack (Female) Bulkhead Adapter, DC-6GHz VSWR 1.20	Standard	Between Series	N	Jack (Female)	MCX	Jack (Female)			50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)		6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-A2B25A/94-94	SMA Jack (Female) to BNC Jack (Female) Adpter, DC-6GHz VSWR1.20	Standard	Between Series	SMA	Jack (Female)	BNC	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Bayonet		6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			1.20
AD-A1A15A/111-111	SMA Pulg (Male) to SMA Pulg (Male) Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-A1A15A/133-133	SMA Pulg (Male) to SMA Pulg (Male) Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Nickel	Brass	Nickel			1.20
AD-A1A25A/133-H3	SMA Pulg (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.22	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Nickel	Brass	Nickel			1.22
AD-K2K25A/9X-9X	2.92mm Jack (Female) to 2.92mm Jack (Female) Adapter, DC-40 GHz VSWR 1.15	Precision	In-Series	2.92mm	Jack (Female)	2.92mm	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		40	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
AD-K2K25B/9X-9X	2.92mm Jack (Female) to 2.92mm Jack (Female) Adapter, DC-40 GHz VSWR 1.15	Precision	In-Series	2.92mm	Jack (Female)	2.92mm	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		40	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
VH-AD-K2K25A/9X-9X	2.92mm Jack (Female) to 2.92mm Jack (Female) Adapter With Venting Hole For TVACApplication, DC-40 GHz VSWR 1.15	Precision	In-Series	2.92mm	Jack (Female)	2.92mm	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		40	Stainless Steel	Passivated	Stainless Steel	Passivated			1.25
ADT-B1B1B15A/144-144-144	BNC Plug (Male) to BNC Plug (Male) to BNC Plug (Male) T-Adapter, DC-10GHz	Standard	In-Series	BNC	Plug (Male)	BNC	Plug (Male)	BNC	Plug (Male)	50	T-Adapter	None	Bayonet	Bayonet	Bayonet	10	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	N/A
AD-A1A75A/111-11	SMA Plug (Male) to SMA R/P Jack (Female) Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Plug (Male)	SMA	R/P Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-B1N25A/144-H4	BNC Plug (Male) to N Jack (Female) Adapter, DC-4.0 GHz VSWR 1.20	Standard	Between Series	N	Jack (Female)	BNC	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Bayonet		4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			1.20
ADT-B2B2B25A/13-13-13	BNC Jack (Female) to BNC Jack (Female) to BNC Jack (Female) T-Adapter, DC-10GHz VSWR 1.3	Standard	In-Series	BNC	Jack (Female)	BNC	Jack (Female)	BNC	Jack (Female)	50	T-Adapter	None	Bayonet	Bayonet	Bayonet	10	Brass	Nickel	Brass	Nickel	Brass	Nickel	1.30
AD-A1A15A-BH/111-111	SMA Plug (Male) to SMA Plug (Male) Bulkhead Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)			50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.20
AD-PC1PCN15A/9XX-9XX	3.5mm Plug (Male) to Precision N Plug (Male) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision N	Plug (Male)	3.5mm	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
