Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Body Style	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max	Impedance 1(Ohm)	Impedance 2(Ohm)
MP-A25F17A-2G/H4-H44	SMA 50 Ohm Jack (Female) to F 75 Ohm Plug (Male) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	F	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-A25F17A-2G/H3-H33	SMA 50 Ohm Jack (Female) to F 75 Ohm Plug (Male) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	F	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	50	75
MP-N25N27A-2G/H4-H4	N 50 Ohm Jack (Female) to N 75 Ohm Jack (Female) Matching Pads, DC-2GHz VSWR 1.25	Standard	In-Series	N	Jack (Female)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N25F17A-2G/H4-H44	N 50 Ohm Jack (Female) to F 75 Ohm Plug (Male ) Matching Pads, DC-2GHz VSWR 1.25	Standard	Between Series	N	Jack (Female)	F	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N25F17A-2G/H3-H33	N 50 Ohm Jack (Female) to F 75 Ohm Plug (Male ) Matching Pads, DC-2GHz VSWR 1.25	Standard	Between Series	N	Jack (Female)	F	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	50	75
MP-N15F27A-2G/H44-H4	N 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	N	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N15F27A-2G/H33-H3	N 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	N	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	50	75
MP-N25F27A-2G/H4-H4	N 50 Ohm Jack (Female) to F 75 Ohm Jack (Female) Matching Pads, DC-2GHz VSWR 1.25	Standard	Between Series	N	Jack (Female)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N25F17A-2G/H3-H33	N 50 Ohm Jack (Female) to F 75 Ohm Plug (Male ) Matching Pads, DC-2GHz VSWR 1.25	Standard	Between Series	F	Plug (Male)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	75	50
MP-N15N27A-3G/9XX-9X	N 50 Ohm Plug (Male) to N 75 Ohm Jack (Female) Matching Pad, DC-3GHz VSWR 1.35	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	50	75
MP-A25F27A-2G/H4-H4	SMA 50 Ohm Jack (Female) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Jack (Female)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N15N27A-2G/144-H4	N 50 Ohm Plug (Male) to N 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N15N17A-2G/144-144	N 50 Ohm Plug (Male) to N 75 Ohm Plug (Male) Matching Pad, DC-2GHz VSWR 1.25	Standard	In-Series	N	Plug (Male)	N	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N15F27B-2G/H33-H3	N 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	N	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	50	75
MP-N15F17A-2G/H44-H44	N 50 Ohm Plug (Male) to F 75 Ohm Plug (Male) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	N	Plug (Male)	F	Plug (Male)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-N15B27A-2G/H44-H4	N 50 Ohm Plug (Male) to BNC 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	N	Plug (Male)	BNC	Jack (Female)	Straight	Threaded (Screw-lock)	Bayonet	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-B15T27-2GA/H44-H4	BNC 50 Ohm Plug (Male) to TNC 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.20	Standard	Between Series	BNC	Plug (Male)	TNC	Jack (Female)	Straight	Bayonet	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	50	75
MP-N25N27A-2G/H4-H4	N 50 Ohm Jack (Female) to N 75 Ohm Jack (Female) Matching Pads, DC-2GHz VSWR 1.25	Standard	In-Series	N	Jack (Female)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	75	50
MP-N25F17A-2G/H4-H44	N 50 Ohm Jack (Female) to F 75 Ohm Plug (Male ) Matching Pads, DC-2GHz VSWR 1.25	Standard	Between Series	F	Plug (Male)	N	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	75	50
MP-B15F27A-2G/H44-H4	BNC 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	BNC	Plug (Male)	F	Jack (Female)	Straight	Bayonet	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-B15B27A-2G/H44-H4	BNC 50 Ohm Plug (Male) to BNC 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	Straight	Bayonet	Bayonet	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-A15F27A-2G-IPX7/H44-H4	SMA 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-A15F27A-2G/H44-H4	SMA 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	50	75
MP-A15F27A-2G/H33-H3	SMA 50 Ohm Plug (Male) to F 75 Ohm Jack (Female) Matching Pad, DC-2GHz VSWR 1.25	Standard	Between Series	SMA	Plug (Male)	F	Jack (Female)	Straight	Threaded (Screw-lock)	Threaded (Screw-lock)	2.0	Brass	Nickel	Brass	Nickel	1.25	50	75

RF Impedance Matching Pads
