Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Connector 3 Series (T-Adapter)	Connector 3 Gender (T-Adapter)	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Connector 3 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	Connector 3 Body Material	Connector 3 Body Plating	VSWR, Max
ADT-A2A1A25A/91-911-91	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	SMA	Jack (Female)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	N/A
ADT-A2A1A25A/9Q-1QQ-9Q	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	SMA	Plug (Male)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	N/A
AD-PM2PM25A-BL10.49/99-99	SMPM Jack (Female) to SMPM Jack (Female) Bullet Adapter, .413 inch Length, DC- 50 GHz VSWR 1.5	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)			50	Straight	None	Snap-On	Snap-On		50	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.50
AD-PC1V25A/9XX-9X	3.5mm Plug (Male) to 1.85mm Jack (Female) Adapter, DC-33GHz VSWR 1.15	Precision	Between Series	3.5mm	Plug (Male)	1.85mm	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		33	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
AD-U1U15A/144-144	UHF Plug (Male) to UHF Plug (Male) Adapter, DC- 300MHz	Standard	In-Series	UHF	Plug (Male)	UHF	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		300MHz	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			N/A
ADT-A2A1A25A/9X-9XX-9X	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz VSWR 2.25	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	SMA	Jack (Female)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Stainless Steel	Passivated	Stainless Steel	Passivated	Stainless Steel	Passivated	2.25
ADT-A2A1A25A/94-144-94	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	SMA	Jack (Female)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	N/A
AD-PCN2PCN25B-PF/9X-9X	Precision N Jack (Female) to Precision N Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-18GHz VSWR 1.2	Precision	In-Series	Precision N	Jack (Female)	Precision N	Jack (Female)			50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Stainless Steel	Passivated	Stainless Steel	Passivated			1.20
AD-PCN2PCN25A-PF/94-94	Precision N Jack (Female) to Precision N Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-18GHz VSWR 1.2	Precision	In-Series	Precision N	Jack (Female)	Precision N	Jack (Female)			50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			1.20
AD-T1T25A/H33-H3	TNC Plug (Male) to TNC Jack (Female) Adapter, DC-11 GHz VSWR 1.25	Standard	In-Series	TNC	Plug (Male)	TNC	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		11	Brass	Nickel	Brass	Nickel			1.25
AD-T1T25A/H44-H4	TNC Plug (Male) to TNC Jack (Female) Adapter, DC-11 GHz VSWR 1.25	Standard	In-Series	TNC	Jack (Female)	TNC	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy			1.25
AD-PCA2PCA25B-PF/9X-9X	Precision SMA Jack (Female) to Precision SMA Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
ADT-A2A1A25A/91-111-91	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	SMA	Plug (Male)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	N/A
AD-PCA2PCA25B-PF/91-91	Precision SMA Jack (Female) to Precision SMA Jack (Female) Panel 4 Hole Flange Mount Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.15
AD-PCA2PCA25B/91-91	Precision SMA Jack (Female) to Precision SMA Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.15
AD-PCA2PCA25B/93-93	Precision SMA Jack (Female) to Precision SMA Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Nickel	Brass	Nickel			1.15
ADT-B2B1B27A/H3-133-H3	BNC Jack (Female) to BNC Plug (Male) to BNC Jack (Female) T-Adapter, 75 Ohm DC-1.0 GHz	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	BNC	Jack (Female)	75	T-Adapter	None	Bayonet	Bayonet	Bayonet	1.0	Brass	Nickel	Brass	Nickel	Brass	Nickel	N/A
ADT-A2A1A25A/94-144-94	SMA Jack (Female) to SMA Plug (Male) to SMA Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	SMA	Plug (Male)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	N/A
ADT-N2N1N25A/H4-144-H4	N Jack (Female) to N Plug (Male) to N Jack (Female) T-Adapter, DC-12.4GHz	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	N	Jack (Female)	50	T-Adapter	None	Threaded (Screw-lock)	Threaded (Screw-lock)	Threaded (Screw-lock)	12.4	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	N/A
AD-PCA2PCA25B-BH/91-91	Precision SMA Jack (Female) to Precision SMA Jack (Female) Bulkhead Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.15
AD-PC1V25A/9XX-9X	3.5mm Plug (Male) to 1.85mm Jack (Female) Adapter, DC-33GHz VSWR 1.15	Precision	Between Series	1.85mm	Jack (Female)	3.5mm	Plug (Male)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		33	Stainless Steel	Passivated	Stainless Steel	Passivated			1.15
AD-PCA2PCA25A-BH/91-91	Precision SMA Jack (Female) to Precision SMA Jack (Female) Bulkhead Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Jack (Female)			50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.15
AD-PCA1PCA25C/111-11	Precision SMA Plug (Male) to Precision SMA Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Plug (Male)	Precision SMA	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)			1.15
AD-PCA1PCA25B/933-93	Precision SMA Plug (Male) to Precision SMA Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	In-Series	Precision SMA	Plug (Male)	Precision SMA	Jack (Female)			50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)		27	Brass	Nickel	Brass	Nickel			1.15
