| SMA2H1B50-0080A/91 |
SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20
|
![SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20]( "SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20")
|
Standard |
50 |
Straight |
18 |
1.20 |
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Mechanical Captivation |
Flat End |
| Q1HA50-2235A/9XX |
2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz
|
![2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz]( "2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz")
|
Precision |
50 |
Straight |
50 |
|
PCB Connector |
2.4mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| Q1HA50-2235B/9XX |
2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz
|
![2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz]( "2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz")
|
Precision |
50 |
Straight |
50 |
|
PCB Connector |
2.4mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| Q1HA50-2235C/9XX |
2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz
|
![2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz]( "2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz")
|
Precision |
50 |
Straight |
50 |
|
PCB Connector |
2.4mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| Q1HA50-2235D/9XX |
2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz
|
![2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz]( "2.4mm Plug (male) PCB End Launch Straight Connector, DC-50GHz")
|
Precision |
50 |
Straight |
50 |
|
PCB Connector |
2.4mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K2HA50-1892B/9X |
2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25
|
![2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25]( "2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25")
|
Precision |
50 |
Straight |
40 |
1.25 |
PCB Connector |
2.92mm |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K2HA50-1892A/9X |
2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| BNC2I50-1820A/H3 |
BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40
|
![BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40]( "BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40")
|
Standard |
50 |
Straight |
4.0 |
1.40 |
PCB Connector |
BNC |
Jack (Female) |
Bayonet |
Soldered |
None |
Brass |
Nickel |
Mechanical Captivation |
Coaxial End |
| SMA2HA50-1892A-LP/9X |
SMA Jack (Female) PCB End Launch Straight Connector, DC-27GHz (Low Profile)
|
![SMA Jack (Female) PCB End Launch Straight Connector, DC-27GHz (Low Profile)]( "SMA Jack (Female) PCB End Launch Straight Connector, DC-27GHz (Low Profile)")
|
Standard |
50 |
Straight |
27 |
|
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| SMA2H2A50-1405A/91 |
SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30
|
![SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30]( "SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30")
|
Standard |
50 |
Straight |
18 |
1.30 |
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Mechanical Captivation |
Coaxial End |
| SMA2JA50-2210A/91 |
SMA Jack (Female) PCB Edge Mount Straight For Bulkhead Connector, DC-18GHz VSWR1.40
|
![SMA Jack (Female) PCB Edge Mount Straight For Bulkhead Connector, DC-18GHz VSWR1.40]( "SMA Jack (Female) PCB Edge Mount Straight For Bulkhead Connector, DC-18GHz VSWR1.40")
|
Standard |
50 |
Straight |
18 |
1.40 |
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
Bulkhead |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Mechanical Captivation |
Coaxial End |
| SMA2LA50-0963A/9X |
SMA Jack (Female) PCB Compression Mount Straight Connector, DC-27GHz
|
![SMA Jack (Female) PCB Compression Mount Straight Connector, DC-27GHz]( "SMA Jack (Female) PCB Compression Mount Straight Connector, DC-27GHz")
|
Standard |
50 |
Straight |
27 |
|
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| SMA2H3B50-0100A/91 |
SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30
|
![SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30]( "SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30")
|
Standard |
50 |
Straight |
18 |
1.30 |
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Mechanical Captivation |
Flat End |
| BNC2I50-1820A/94 |
BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40
|
![BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40]( "BNC Jack (Female) PCB Through Hole Straight Connector, DC-4GHz VSWR1.40")
|
Standard |
50 |
Straight |
4.0 |
1.40 |
PCB Connector |
BNC |
Jack (Female) |
Bayonet |
Soldered |
None |
Brass |
Copper-Tin Zinc Alloy |
Mechanical Captivation |
Coaxial End |
| SMA2H3B50-0110A/91 |
SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30
|
![SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30]( "SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30")
|
Standard |
50 |
Straight |
18 |
1.30 |
PCB Connector |
SMA |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Brass |
Gold Plating (Non-magnetic nickel-phosphorus underplating) |
Mechanical Captivation |
Flat End |
| K1HA50-2226B/9XX |
2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K1HA50-2226A/9XX |
2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| PCA1HA50-2226A-LP/9XX |
Precision SMA Plug (Male) PCB End Lauch Straight Connector, DC-26.5GHz VSWR 1.40
|
![Precision SMA Plug (Male) PCB End Lauch Straight Connector, DC-26.5GHz VSWR 1.40]( "Precision SMA Plug (Male) PCB End Lauch Straight Connector, DC-26.5GHz VSWR 1.40")
|
Precision |
50 |
Straight |
26.5 |
1.40 |
PCB Connector |
Precision SMA |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K1HA50-2226A-LP/9XX |
2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K1HA50-2226C/9XX |
2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K2HA50-1892A-LP/9X |
2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K2HA50-1892D/9X |
2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25
|
![2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25]( "2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25")
|
Precision |
50 |
Straight |
40 |
1.25 |
PCB Connector |
2.92mm |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K1HA50-2226D/9XX |
2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40
|
![2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40]( "2.92mm Plug (male) PCB End Launch Straight Connector, DC-40GHz VSWR1.40")
|
Precision |
50 |
Straight |
40 |
1.40 |
PCB Connector |
2.92mm |
Plug (Male) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
| K2HA50-1892C/9X |
2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25
|
![2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25]( "2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25")
|
Precision |
50 |
Straight |
40 |
1.25 |
PCB Connector |
2.92mm |
Jack (Female) |
Threaded (Screw-lock) |
Soldered |
None |
Stainless Steel |
Passivated |
Mechanical Captivation |
Coaxial End |
