RF Adapters
View
Select Parameters Above to Display in the Window Below.
| Order No | Product Name | Photo zoom_in | Type Design | Connection Type | Connector 1 Series | Connector 1 Gender | Connector 2 Series | Connector 2 Gender | Connector 3 Series | Connector 3 Gender | Impedance (Ohm) | Body Style | Panel Mount | Connector 1 Connection Method | Connector 2 Connection Method | Connector 3 Connection Method | Frequency, Max (GHz) | Connector 1 Body Material | Connector 1 Body Plating | Connector 2 Body Material | Connector 2 Body Plating | Connector 3 Body Material | Connector 3 Body Plating | VSWR, Max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AD-A1BA15A/1XX-1X | BMA Male to SMA Male Adapter, DC-26.5 GHz |
|
Standard | Between Series | BMA | Plug (Male) | SMA | Plug (Male) | 50 | Straight | None | Slide-On | Threaded (Screw-lock) | 26.5 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-D2D25A-BH/84-84 | 7/16 Female Bulkhead Adapter, DC-7.5 GHz |
|
Standard | In-Series | 7/16 | Jack (Female) | 7/16 | Jack (Female) | 50 | Straight | Bulkhead | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.22 | |||||
| ADT-B1B2B25A/133-H3-H3 | BNC T-Adapter, Female-Male-Female, 10 GHz |
|
Standard | In-Series | BNC | Jack (Female) | BNC | Plug (Male) | BNC | Jack (Female) | 50 | T-Adapter | None | Bayonet | Bayonet | Bayonet | 10 | Brass | Nickel | Brass | Nickel | Brass | Nickel | N/A |
| AD-Q1K25A/9XX-9X | 2.4mm Male to 2.92mm Female Adapter, DC-40 GHz |
|
Precision | Between Series | 2.4mm | Plug (Male) | 2.92mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 40 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-Q1Q25A/9XX-9X | 2.4mm Female to Male Adapter, 50 GHz VSWR 1.2 |
|
Precision | In-Series | 2.4mm | Jack (Female) | 2.4mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 50 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.20 | |||||
| AD-K1Q25A/9XX-9X | 2.4mm Female to 2.92mm Male Adapter, 40 GHz |
|
Precision | Between Series | 2.4mm | Jack (Female) | 2.92mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 40 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-PCT1A25A/9XX-91 | Precision TNC Male to SMA Female Adapter, 18 GHz |
|
Precision | Between Series | Precision TNC | Plug (Male) | SMA | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 18 | Stainless Steel | Passivated | Brass | Gold Plating (Non-magnetic nickel-phosphorus underplating) | 1.25 | |||||
| AD-PCA2P25A/9X-99 | Precision SMA to SMP Female Adapter, 27 GHz |
|
Precision | Between Series | Precision SMA | Jack (Female) | SMP | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Snap-On | 27 | Stainless Steel | Passivated | Beryllium Copper | Gold Plating (Non-magnetic nickel-phosphorus underplating) | 1.15 | |||||
| AD-T1N25C/133-H3 | N Female to TNC Male Adapter, DC-11 GHz |
|
Standard | Between Series | N | Jack (Female) | TNC | Plug (Male) | 50 | Straight | None | Bayonet | Threaded (Screw-lock) | 11 | Brass | Nickel | Brass | Nickel | 1.20 | |||||
| AD-A1N25A-PF/H11-H4 | SMA Male to N Female 4 Hole Adapter, 11 GHz |
|
Standard | Between Series | SMA | Plug (Male) | N | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Gold Plating (Non-magnetic nickel-phosphorus underplating) | Brass | Copper-Tin-Zinc Alloy | 1.15 | |||||
| AD-A1T25B/933-93 | SMA Male to TNC Female Adapter, 11 GHz VSWR 1.2 |
|
Standard | Between Series | SMA | Plug (Male) | TNC | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Nickel | Brass | Nickel | 1.20 | |||||
| AD-N2D25A-PF/H4-H4 | N to 7/16 Female 4 Hole Adapter, DC-0.5 GHz |
|
Standard | Between Series | N | Jack (Female) | 7/16 | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 0.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.15 | |||||
| AD-PCA1Q25B/9XX-9X | 2.4mm Female to Precision SMA Male Adapter, 27 GHz |
|
Precision | Between Series | 2.4mm | Jack (Female) | Precision SMA | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-K2P25A/9X-99 | 2.92mm to SMP Female Adapter, DC-40 GHz |
|
Precision | Between Series | 2.92mm | Jack (Female) | SMP | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Snap-On | 40 | Stainless Steel | Passivated | Beryllium Copper | Gold Plating (Non-magnetic nickel-phosphorus underplating) | 1.50 | |||||
| AD-PCN1PCN25B/9XX-9X | Precision N Female to Male Adapter, DC-18 GHz |
|
Precision | In-Series | Precision N | Jack (Female) | Precision N | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 18 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-K1V25A/9XX-9X | 2.92mm Male to 1.85mm Female Adapter, 40 GHz |
|
Precision | Between Series | 2.92mm | Plug (Male) | 1.85mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 40 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-A1N25A-PF/H31-H3 | SMA Male to N Female 4 Hole Adapter, 11 GHz |
|
Standard | Between Series | SMA | Plug (Male) | N | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Nickel | Brass | Nickel | 1.15 | |||||
| AD-Q1K25A/9XX-9X | 2.92mm Female to 2.4mm Male Adapter, DC-40 GHz |
|
Precision | Between Series | 2.92mm | Jack (Female) | 2.4mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 40 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-A1N25A-PF/H11-H3 | SMA Male to N Female 4 Hole Adapter, 11 GHz |
|
Standard | Between Series | SMA | Plug (Male) | N | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Gold Plating (Non-magnetic nickel-phosphorus underplating) | Brass | Nickel | 1.15 | |||||
| AD-T1A25A/144-94 | TNC Male to SMA Female Adapter, DC-11 GHz |
|
Standard | Between Series | TNC | Plug (Male) | SMA | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.25 | |||||
| AD-N2M25A-BH/94-94 | MCX to N Female Bulkhead Adapter, DC-6 GHz |
|
Standard | Between Series | MCX | Jack (Female) | N | Plug (Male) | 50 | Straight | Bulkhead | Threaded (Screw-lock) | Threaded (Screw-lock) | 6.0 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.20 | |||||
| AD-Q2K25A/9X-9X | 2.4mm to 2.92mm Female Adapter, DC-40 GHz |
|
Precision | Between Series | 2.4mm | Jack (Female) | 2.92mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 40 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-E1U25A/13-93 | FME Male to UHF Female Adapter, DC-300 MHz |
|
Standard | Between Series | FME | Plug (Male) | UHF | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 300MHz | Brass | Nickel | Brass | Nickel | N/A | |||||
| AD-LC1D25A/044-04 | LC Male to 7/16 Female Adapter, DC-1 GHz |
|
Standard | Between Series | LC | Plug (Male) | 7/16 | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 1.0 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.25 |
