Key Specifications
Description
Precision TNC Male to Precision TNC Male Straight Adapter, DC-18 GHz, VSWR ≤ 1.25, 50 Ω Impedance.
ROSNOL AD-PCT1PCT15A1/9XX-9XX is a Precision TNC Plug (Male) to Precision TNC Plug (Male) straight RF adapter designed for 50 Ω applications from DC to 18 GHz. With VSWR ≤ 1.25, low insertion loss, and stable RF performance, this adapter is suitable for precision measurement systems, RF test equipment, and microwave interconnect applications.
The adapter features beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating for excellent conductivity and contact reliability. The body and fastening nut are constructed from passivated stainless steel, while PTFE insulators and silicone rubber gaskets enhance electrical stability and environmental durability. Key specifications include insulation resistance ≥ 5 GΩ, contact resistance ≤ 1.5 mΩ, test voltage 1500 Vrms, and working voltage 500 Vrms.
A screw-on coupling mechanism and durability of over 500 mating cycles provide dependable long-term performance. This adapter is widely used in RF laboratories, microwave communication systems, aerospace electronics, and precision instrumentation requiring stable high-frequency signal transmission.
