Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
HN2BF50-3607A/G3	HN Jack (Female) Bulkhead Straight Connector, DC-4GHz VSWR1.30		50	Straight	4.0	1.30	Bulkhead Receptacle	HN	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel		Solder End
SMA2FA50-1550A/91	SMA Jack (Female) Bulkhead Straight Connector, DC-18 GHz VSWR1.25		50	Straight	18	1.25	Bulkhead Receptacle	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
TNC1FB50-3400A/133	TNC Plug (Male) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Solder End
TNC1FB50-3400A/1XX	TNC Plug (Male) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC1FB50-3000A/144	TNC Plug (Male) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC1FB50-3000A/133	TNC Plug (Male) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Solder End
TNC1FB50-3000A/1XX	TNC Plug (Male) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC2FB50-2700A/HX	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC2FB50-2700A/H4	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC2FB50-2700A/H3	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Solder End
TNC2FB50-2670B/HX	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC2FB50-2670B/H4	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC2FB50-2670B/H3	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Solder End
TNC2FB50-2670A/HX	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC2FB50-2670A/H4	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC2FB50-2670A/H3	TNC Jack (Female) Bulkhead Straight Connector, DC-11 GHz	Standard	50	Straight	11		Bulkhead Receptacle	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Solder End
SMS1FB50-1750A/911	SMS Plug (Male) Bulkhead Straight Connector, DC-4 GHz	Standard	50	Straight	4.0		Bulkhead Receptacle	SMS	Plug (Male)	Slide-On	Soldered	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Solder End
SMS2FB50-1500A/11	SMS Jack (Female) Bulkhead Straight Connector, DC-4 GHz	Standard	50	Straight	4.0		Bulkhead Receptacle	SMS	Jack (Female)	Slide-On	Soldered	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Solder End
SMP1FA50-LD1000A/91	SMP Plug (Male) Bulkhead Straight Connector Limited Detent, DC-40 GHz VSWR1.30	Standard	50	Straight	40	1.30	Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SMP1FA50-LD0668B/9X	SMP Plug (Male) Bulkhead Straight Connector Limited Detent, DC-26.5 GHz	Standard	50	Straight	26.5		Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMP1FA50-SB1015A/9X	SMP Plug (Male) Bulkhead Straight Connector Full Detent, DC-40 GHz VSWR1.15	Standard	50	Straight	40	1.15	Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMP1FA50-FD1011A/9X	SMP Plug (Male) Bulkhead Straight Connector Full Detent, DC-26.5 GHz VSWR1.29	Standard	50	Straight	26.5	1.29	Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMP1FA50-FD0856A/9X	SMP Plug (Male) Bulkhead Straight Connector Full Detent, DC-40 GHz VSWR1.50	Standard	50	Straight	40	1.50	Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMP1FA50-FD0432A/77	SMP Plug (Male) Bulkhead Straight Connector Full Detent, DC-26.5 GHz VSWR1.15	Standard	50	Straight	26.5	1.15	Bulkhead Receptacle	SMP	Plug (Male)	Snap-On	Soldered	Bulkhead	Kovar per ASTM F 15-78	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
