2.92mm Plug (Male) to 2.92mm Jack (Female) Mitered Right Angle Adapter, DC-40GHz VSWR1.25

2.92mm Plug (Male) to 2.92mm Jack (Female) | L-Adapter | Passivated Stainless Steel Body

The ROSNOL ASL-K1K25A/9XX-9X is a precision-engineered 2.92mm L-adapter optimized for RF systems up to 40 GHz. It features a screw-lock coupling mechanism, ≥500 mating cycles, center contact captivation ≥20 N, and torque rating up to 1.7 Nm. Electrical specifications include 50 Ω impedance, VSWR ≤1.25 (≥19.08 dB), insertion loss ≤0.05×√F(GHz) dB, RF leakage ≥100 dB up to 1 GHz, and power handling of 20 W. The adapter is rated for 750 V rms test voltage and 250 V rms working voltage.

Built with a passivated stainless steel body and coupling nut, the ASL-K1K25A/9XX-9X includes beryllium copper center contacts with gold plating, PEI insulators, and a silicone rubber gasket. It is mechanically compatible with 3.5mm and SMA connectors, and performs reliably across a temperature range of -55°C to +165°C, meeting MIL-STD-202 standards for environmental durability.

ROSNOL’s precision-engineered solutions offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring environmental safety and global regulatory alignment. Customization services for materials, plating, and mechanical design are available to support specialized requirements across a wide range of RF and microwave applications.
