2.92mm to SMA Female Adapter, DC-18 GHz

Order No:AD-K2A25A/91-91
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
Between Series
Connector 1 Series:
2.92mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
SMA
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
18
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
VSWR, Max:
1.15

Description

2.92mm Female to SMA Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.

ROSNOL AD-K2A25A/91-91 is a precision RF adapter featuring a 2.92mm Jack (Female) to SMA Jack (Female) configuration. Designed for 50 Ω systems, it operates from DC to 18 GHz with VSWR ≤ 1.15 and insertion loss ≤ 0.05 × √F (GHz) dB. This adapter provides accurate impedance matching and reliable signal transmission for microwave testing, RF instrumentation, and communication applications.

The adapter incorporates precision-machined brass bodies with gold plating over non-magnetic nickel-phosphorus underplating, delivering excellent conductivity and corrosion resistance. Both center contacts are manufactured from beryllium copper and feature the same gold-plated finish to ensure low contact resistance and consistent electrical performance. PTFE and PS insulators provide stable dielectric properties, while screw-lock coupling supports secure connection and a mating life of at least 500 cycles.

With high-quality gold-plated construction, low VSWR performance, and dependable mechanical durability, the AD-K2A25A/91-91 is well suited for microwave laboratories, RF validation systems, antenna measurement environments, and high-frequency communication equipment requiring precision female-to-female RF adaptation.
