Key Specifications
Description
2.4mm Male to 2.92mm Female Straight Adapter, DC-40 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-Q1K25A/9XX-9X is a high-performance RF adapter designed to interface a 2.4 mm Plug (Male) with a 2.92 mm Jack (Female). Featuring 50 Ω impedance, DC to 40 GHz frequency coverage, VSWR ≤ 1.15, and insertion loss ≤ 0.05 × √F (GHz) dB, this adapter delivers low-loss signal transmission and reliable broadband RF performance.
The adapter incorporates beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating for superior conductivity and long-term reliability. Both connector bodies are manufactured from passivated stainless steel, while PEI insulators ensure stable dielectric characteristics. The 2.4 mm interface includes a silicone rubber gasket and stainless steel coupling nut to enhance durability and environmental resistance. Electrical specifications include insulation resistance ≥ 5 GΩ, RF leakage ≥ 100 dB up to 1 GHz, and power handling up to 16 W.
Designed for demanding RF and microwave environments, this adapter offers precise impedance matching, low return loss, and mechanical robustness. It is ideal for high-frequency test systems, RF measurement equipment, microwave communications, aerospace applications, and millimeter-wave instrumentation.
