Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
ADL-PCA1PCA25C/9XX-9X	Precision SMA Plug (Male) to Precision SMA Jack (Female) Right Angle Adapter, DC-26.5GHz VSWR 1.25	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-43101PCN25A/144-94	4.3/10 Plug (Male) to Precision N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Precision	Between Series	4.3-10	Plug (Male)	Precision N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-A1A55A/911-911	SMA Plug (Male) to SMA R/P Plug (Male) Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	R/P Plug (Male)	SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
ADL-A1A25E/9XX-9X	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
ADL-A1A25C/9XX-9X	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
ADL-B1B25A/9XX-9X	BNC Plug (Male) to BNC Jack (Female) Right Angle Adapter, DC-4GHz VSWR 1.20	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Right Angle	None	Bayonet	Bayonet	4.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
ADL-N1N25A/H33-H3	N Plug (Male) to N Jack (Female) Right-Angle Adatper, DC-11GHz VSWR 1.20	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Nickel	Brass	Nickel	1.20
AD-43101PCN25A/H44-H4	4.3-10 Plug (Male) to Precision N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Precision	Between Series	Precision N	Jack (Female)	4.3-10	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
ADL-A1A25C/9QQ-9Q	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
ADL-A1A25B/9XX-9X	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.25	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
ADL-PCA1PCA25C/911-91	Precision SMA Plug (Male) to Precision SMA Jack (Female) Right Angle Adapter, DC-26.5GHz VSWR 1.20	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
ADL-D2D25A/H4-H4-LP	7/16 Jack (Female) to 7/16 Jack (Female) Right-Angle Adapter, DC-7.5GHz VSWR 1.25	Standard	In-Series	7/16	Jack (Female)	7/16	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	7.5	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25
ADL-B1B25A/133-93	BNC Plug (Male) to BNC Jack (Female) Right Angle Adapter, DC-4GHz VSWR 1.25	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Right Angle	None	Bayonet	Bayonet	4.0	Brass	Nickel	Brass	Nickel	1.25
ADL-A1A25C/911-91	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
ADL-A1A25C/133-H3	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.15
AD-43101PCN25A/144-9X	4.3-10 Plug (Male) to Precision N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Precision	Between Series	Precision N	Jack (Female)	4.3-10	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Stainless Steel	Passivated	Brass	Copper-Tin-Zinc Alloy	1.15
ADL-N1N25A/H44-H4	N Plug (Male) to N Jack (Female) Right-Angle Adatper, DC-11GHz VSWR 1.20	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
ADL-A1A25A/911-91	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.25	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-43101PCN25A/H44-H4	4.3-10 Plug (Male) to Precision N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Precision	Between Series	4.3-10	Plug (Male)	Precision N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
ADL-A1A25A/133-H3	SMA Plug (Male) to SMA Jack (Female) Right-Angle Adapter, DC-18GHz VSWR 1.25	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.25
ADL-A1A15C/9XX-9XX	SMA Plug (Male) to SMA Plug (Male) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
ADL-N1N25A/H44-H4	N Plug (Male) to N Jack (Female) Right-Angle Adatper, DC-11GHz VSWR 1.20	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
ADL-A1A15C/911-911	SMA Plug (Male) to SMA Plug (Male) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
ADL-A1A15A/9XX-9XX	SMA Plug (Male) to SMA Plug (Male) Right-Angle Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Plug (Male)	50	Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15

RF Adapters
