Panel Connectors

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
SMA2GTA50-2000A/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-2000A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1850A-EC/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Coaxial End
SMA2GTA50-1850A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1850A/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-1850A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1745A-EC/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Coaxial End
SMA2GTA50-1745A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1745A/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-1745A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1740A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1740A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1700B/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-1700A-EC/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Coaxial End
SMA2GTA50-1700A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1700A/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-1700A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1690A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1690A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2GTA50-1687A-EC/9Q	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1650A-EC/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Coaxial End
SMA2GTA50-1650A-EC/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Coaxial End
SMA2GTA50-1650A/9X	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2GTA50-1650A/91	SMA Jack (Female) Straight Connector 2 Hole Flange, 12.22mm (.481 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
