Key Specifications
Description
SMA Female Connector, 2 Hole Flange Mount, Stub Terminal, 12.22 mm Hole Spacing, 50 Ω, DC-18 GHz VSWR ≤1.30.
ROSNOL SMA2GTA50-2450A/91 is a high-performance SMA Jack (Female) connector designed for RF and microwave applications requiring reliable panel integration and consistent signal transmission. This 50 Ohm connector features a 2-hole flange mount configuration, stub terminal design, and 12.22 mm (0.481 inch) hole spacing for secure installation. Operating from DC to 18 GHz, it delivers a VSWR of ≤ 1.30 and low insertion loss of ≤ 0.04 × √F (GHz) dB, supporting efficient RF performance across a broad frequency range. Additional electrical specifications include insulation resistance of at least 5 GΩ, center contact resistance of ≤ 3 mΩ, and power handling capability up to 200 W at 2 GHz.
The connector incorporates a beryllium copper center contact with gold plating over non-magnetic nickel-phosphorus underplating to ensure excellent conductivity and durability. The body is manufactured from brass with gold plating and matching underplating, while the PTFE insulator provides stable dielectric performance. Mechanical features include a screw-on coupling mechanism, soldered center contact, mechanical captivation structure, a minimum mating life of 500 cycles, and an operating temperature range from -65°C to +165°C. The mounting structure utilizes 12.22 mm (0.481 inch) hole spacing to support standardized panel integration.
This SMA Jack (Female) RF connector is suitable for RF communication systems, wireless infrastructure, antenna interfaces, microwave modules, signal distribution equipment, and precision test instruments. Its low insertion loss, durable plated construction, and dependable flange-mount design make it an effective RF interconnect solution for professional high-frequency applications.
