Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female Connector with Stub Terminal | Solder Attachment | Body | Epoxy Captivation
ROSNOL SMA RF Connector SMA2GTA50-1400C-EC/91 features a stub terminal and solder attachment design with SMA Jack (Female) Connector Solder Attachment 2 Hole Flange Mount hole spacing. It supports frequencies from with impedance of , and maintains VSWR 1.30 and insertion loss .The connector’s center contact is made of with Gold plating, while the body is constructed from with Passivated. This ensures reliable performance and durability in demanding RF applications.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
