Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
SMA Female l Screw-Lock l Stainless Steel Body l Stub Terminal l Mechanical Captivated
The ROSNOL SMA2GTA50-1350C/9X is a 50 Ω RF connector with a 2-hole flange mount and 9mm (.354 inch) hole spacing. It incorporates a screw-lock coupling mechanism and a soldered center contact. The stub terminal design is optimized for RF performance, and mechanical captivation ensures axial retention ≥ 27 N and radial retention ≥ 3 Ncm.Constructed with a passivated stainless steel body and beryllium copper center contact, the connector is plated with 3 µinch gold over 80 µinch non-magnetic nickel-phosphorus underplating. PTFE insulator ensures stable dielectric behavior across temperature variations.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
