Panel Connectors

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
TNC2GFB50-2670A/HX	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC2GFB50-2670A/H4	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC2GFB50-2670A/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Solder End
TNC2GFA54-3720A/H3	TNC Jack (Female) 45 Degrees Connector 4 Hole Flange, 12.7mm (.500 inch) DC-18GHz VSWR1.30	Standard	50	45 Degrees	18	1.30	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2GFA50-3700C/9X	TNC Jack (Female) Straight Connector 4 Hole Flange, 13.5mm (.531 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2GFA50-3270E/9X	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2GFA50-2940A/HX	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2GFA50-2940A/H4	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2GFA50-2940A/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2GFA50-2880D/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2GFA50-2880C/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-8 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2GFA50-2880B/HX	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2GFA50-2880B/H4	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2GFA50-2880B/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2GFA50-2880A/HX	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2GFA50-2880A/H4	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2GFA50-2880A/H3	TNC Jack (female) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC1GTA50-4080A/H33	TNC Plug (Male) Straight Connector 2 Hole Flange, 18mm (.709 inch) DC-4 GHz VSWR1.20	Standard	50	Straight	4.0	1.20	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	2 Hole Flange	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC1GFB50-2910A/1XX	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC1GFB50-2910A/144	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC1GFB50-2910A/133	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Solder End
TNC1GFB50-2850A/1XX	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Solder End
TNC1GFB50-2850A/144	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Solder End
TNC1GFB50-2850A/133	TNC Plug (Male) Straight Connector 4 Hole Flange, 12.7mm (.500 inch) DC-4 GHz VSWR1.09	Standard	50	Straight	4.0	1.09	Panel Connector	TNC	Plug (Male)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Solder End
