Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
SMA Jack (Female) | Solder Attachment | 2-Hole Flange Mount | Brass Body
The ROSNOL SMA2GTA50-1350A/91 is designed for ultra-reliable RF performance, supporting DC to 18 GHz with 50 Ω impedance, VSWR ≤ 1.30, and insertion loss ≤ 0.05√f (GHz) dB. Electrical parameters include insulation resistance ≥ 5 GΩ, test voltage 1000 V rms, and working voltage 480 V rms. Power handling capability reaches 200 W at 2 GHz, ensuring consistent performance in high-frequency applications.Built with a beryllium copper center contact plated with gold over nickel-phosphorus underplating, this connector features a brass body with gold plating for superior durability. PTFE insulation ensures excellent dielectric properties, and the connector withstands temperatures from -65°C to +165°C for long-term reliability.
ROSNOL’s precision-engineered RF connectors deliver high performance at competitive pricing. All components are produced in ISO 9001-certified facilities and meet RoHS and REACH compliance standards. Customization options for plating, materials, and mechanical design are available to meet specialized requirements.
