Panel Connectors

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
SMA2GFD50-1200A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Flat End
SMA2GFD50-1200A-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Flat End
SMA2GFD50-1100B-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Flat End
SMA2GFD50-1100B/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Flat End
SMA2GFD50-1077B-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Flat End
SMA2GFD50-1077B/9Q	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2GFD50-1077B/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Flat End
SMA2GFD50-1077A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Flat End
SMA2GFD50-1077A-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Flat End
SMA2GFD50-1077A/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Flat End
SMA2GFD50-1077A/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2GFD50-1026A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Flat End
SMA2GFD50-1026A-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Flat End
SMA2GFD50-1026A/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Flat End
SMA2GFD50-1026A/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2GFC50-1450B/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 6.35mm (.250 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Semicircular End
SMA2GFC50-1450A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Semicircular End
SMA2GFC50-1450A-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Semicircular End
SMA2GFC50-1200A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Semicircular End
SMA2GFC50-1200A-EC/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Epoxy Captivation	Semicircular End
SMA2GFC50-1450A/91	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semicircular End
SMA2GFB59-1750A/9X	SMA Jack (Female) Right Angle Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Right Angle	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Mechanical Captivation	Solder End
SMA2GFB59-1750A/91	SMA Jack (Female) Right Angle Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Right Angle	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Solder End
SMA2GFB50-1550A-EC/9X	SMA Jack (Female) Straight Connector 4 Hole Flange, 8.64mm (.340 inch) DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	Panel Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	4 Hole Flange	Stainless Steel	Passivated	Epoxy Captivation	Solder End
