Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
SMA Female l Screw-Lock l Stainless Steel Body l Microstrip Terminal l Mechanical Captivated
The ROSNOL model SMA2GTA50-1350C／91 features a 50 Ω impedance and a 2-hole flange mount with 9mm (.354 inch) hole spacing. It utilizes a screw-lock coupling mechanism and includes a soldered centre contact. The terminal type is stub, supporting frequencies from DC to 18 GHz with a VSWR ≤ 1.30 (≥ 17.7 dB), ensuring reliable signal performance.Constructed with a brass body and beryllium copper centre contact, both components are gold plated with a 3 µinch layer over an 80 µinch non-magnetic nickel-phosphorus underplating. The insulator is made of PTFE, providing excellent dielectric properties.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
