PCB Connectors

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
K2HA50-0173A/91	2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25	Precision	50	Straight	40	1.25	PCB Connector	2.92mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
K2LA50-1092B/9Q	2.92mm Jack (Female) PCB Compression Mount Straight Connector, DC-40GHz VSWR1.43	Precision	50	Straight	40	1.43	PCB Connector	2.92mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
W2HA50-1890B-LP/9X	1.00mm Jack (Female) PCB End Launch Straight Connector, DC-110GHz VSWR1.50	Precision	50	Straight	110	1.50	PCB Connector	1.00mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
V2LA50-1118A/9X	1.85mm Jack (female) PCB Compression Mount Straight Connector, DC-67GHz VSWR1.30	Precision	50	Straight	67	1.30	PCB Connector	1.85mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
V2HA50-2071B-LP/9X	1.85mm Jack (Female) PCB End Launch Straight Connector, DC-67GHz	Precision	50	Straight	67		PCB Connector	1.85mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
V2HA50-2071A-LP/9X	1.85mm Jack (Female) PCB End Launch Straight Connector, DC-67GHz	Precision	50	Straight	67		PCB Connector	1.85mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
V2HA50-2070B-LP/9X	1.85mm Jack (Female) PCB End Launch Straight Connector, DC-67GHz	Precision	50	Straight	67		PCB Connector	1.85mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
V1HA50-2200A-LP/9XX	1.85mm Plug (male) PCB End Launch Straight Connector, DC-67GHz VSWR1.40	Precision	50	Straight	67	1.40	PCB Connector	1.85mm	Plug (Male)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
TNC2IA50-3050A/93	TNC Jack (Female) PCB Throught Hole Straight For Bulkhead Connector, DC-6GHz VSWR1.50	Standard	50	Straight	6.0	1.50	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Coaxial End
TNC2I59-3200A/H4	TNC Jack (Female) PCB Throught Hole Right Angle Connector, DC-4GHz VSWR1.20	Standard	50	Right Angle	4.0	1.20	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2I50-2265A/94	TNC Jack (Female) PCB Throught Hole Straight Connector, DC-4GHz VSWR1.20	Standard	50	Straight	4.0	1.20	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2I50-2110A/H4	TNC Jack (Female) PCB Throught Hole Straight Connector, DC-4GHz VSWR1.20	Standard	50	Straight	4.0	1.20	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2I50-1900A/94	TNC Jack (Female) PCB Throught Hole Straight Connector, DC-4GHz VSWR1.20	Standard	50	Straight	4.0	1.20	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
TNC2I50-1820A/94	TNC Jack (Female) PCB Throught Hole Straight Connector, DC-4GHz VSWR1.20	Standard	50	Straight	4.0	1.20	PCB Connector	TNC	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Coaxial End
SSMB2I59-0980A/11	SSMB Jack (Female) PCB Throught Hole Right Angle Connector, DC-3GHz VSWR1.33	Standard	50	Right Angle	3.0	1.33	PCB Connector	SSMB	Jack (Female)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SSMB2I50-1065A/11	SSMB Jack (Female) PCB Throught Hole Straight Connector, DC-3GHz VSWR1.33	Standard	50	Straight	3.0	1.33	PCB Connector	SSMB	Jack (Female)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SSMB2I50-0980A/11	SSMB Jack (Female) PCB Throught Hole Straight Connector, DC-3GHz VSWR1.33	Standard	50	Straight	3.0	1.33	PCB Connector	SSMB	Jack (Female)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SSMA2I59-1334A/9Q	SSMA Jack (Female) PCB Throught Hole Right Angle Connector, DC-18GHz	Precision	50	Right Angle	18		PCB Connector	SSMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMPS1N50-FD305A/99	SMPS Plug (male) PCB Surface Mount Straight Connector, DC-65GHz	Standard	50	Straight	65		PCB Connector	SMP	Plug (Male)	Snap-On	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMPMTHR1NS50-0581A/1Q	SMPM-THR Plug (Male) PCB Surface Mount Straight Connector, DC-20GHz VSWR1.20	Standard	50	Straight	20	1.20	PCB Connector	SMPM	Plug (Male)	Snap-On	Soldered	None	Stainless Steel	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SMPMFD1N50-0400A/11	SMPM Plug (Male) PCB Edge Mount Straight Connector, DC-40GHz	Standard	50	Straight	40		PCB Connector	SMPM	Plug (Male)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SMPM1JS50-0561A/9Q	SMPM Plug (Male) PCB Edge Mount Straight Connector, DC-50GHz VSWR1.30	Standard	50	Straight	50	1.30	PCB Connector	SMPM	Plug (Male)	Snap-On	Soldered	None	Stainless Steel	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SMPM1JF50-0700B/91	SMPM Plug (Male) PCB Edge Mount Straight Connector, DC-65GHz VSWR1.33	Standard	50	Straight	65	1.33	PCB Connector	SMPM	Plug (Male)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End
SMPM1JF50-0700A/91	SMPM Plug (Male) PCB Edge Mount Straight Connector, DC-40GHz VSWR1.22	Standard	50	Straight	40	1.22	PCB Connector	SMPM	Plug (Male)	Snap-On	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Coaxial End

K2HA50-0173A/91

2.92mm Jack (Female) PCB End Launch Straight Connector, DC-40GHz VSWR1.25

Precision

50

Straight

40

1.25

PCB Connector

2.92mm

Jack (Female)

Threaded (Screw-lock)

Soldered

None

Brass

Gold Plating (Non-magnetic nickel-phosphorus underplating)

Mechanical Captivation

Coaxial End

K2LA50-1092B/9Q
