Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Style	Connector Series	Connector Gender	Connection Method	Center Contact	Mount Method	Body Material	Body Plating	Captivated Type	Bankend Type
1032-2I50-1250A/H1	10-32 Jack (Female) PCB Through Hole Straight Connector, DC-2GHz	Standard	50	Straight	2.0		PCB Connector	10-32	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
Q2LA50-1092A-0794/9X	2.4mm Jack (Female) PCB Edge Mount Connector, DC-18GHz VSWR 1.25	Precision	50	Straight	6.0	1.35	PCB Connector	2.4mm	Jack (Female)	Snap-On	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
1032-2I50-1245A/H1	10-32 Jack (Female) PCB Through Hole Straight Connector, DC-2GHz	Standard	50	Straight	2.0		PCB Connector	10-32	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
Q2HA50-2021A/9X	2.4mm Jack (Female) PCB End Launch Straight Connector, DC-50GHz	Precision	50	Straight	50		PCB Connector	2.4mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
Q2HA50-2021B/9X	2.4mm Jack (Female) PCB End Launch Straight Connector, DC-50GHz	Precision	50	Straight	50		PCB Connector	2.4mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
Q2HA50-2021C/9X	2.4mm Jack (Female) PCB End Launch Straight Connector, DC-50GHz	Precision	50	Straight	50		PCB Connector	2.4mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
Q2HA50-2021D/9X	2.4mm Jack (Female) PCB End Launch Straight Connector, DC-50GHz	Precision	50	Straight	50		PCB Connector	2.4mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
K2LA50-1092A/9X	2.92mm Jack (Female) PCB Compression Mount Straight Connector, DC-40GHz VSWR1.35	Precision	50	Straight	40	1.35	PCB Connector	2.92mm	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	Coaxial End
SMA2H3B50-0160A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30	Precision	50	Straight	18	1.30	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H1B50-0110A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20	Standard	50	Straight	18	1.20	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H4B50-0060A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.30	Standard	50	Straight	18	1.30	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H1B50-0050A/91	SMA Jack (Female) PCB End Launch Straight Connectors, DC-18GHz VSWR1.20	Standard	50	Straight	18	1.20	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H1B50-0075A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20	Standard	50	Straight	18	1.20	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H1B50-0100A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20	Standard	50	Straight	18	1.20	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2H1B50-0120A/91	SMA Jack (Female) PCB End Launch Straight Connector, DC-18GHz VSWR1.20	Standard	50	Straight	18	1.20	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Flat End
SMA2I54-1971A/91	SMA Jack (Female) PCB Through Hole 45 Degrees Connector, DC-18GHz VSWR1.25	Standard	50	45 Degrees	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2I50-1150A/91	SMA Jack (Female) PCB Through Hole Straight Connector, DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2I50-1150B/91	SMA Jack (Female) PCB Through Hole Straight Connector, DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2I50-1350A/9Q	SMA Jack (Female) PCB Through Hole Straight Connector, DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2I50-1334A/91	SMA Jack (Female) PCB Through Hole Straight Connector, DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SMA2I50-1334B/91	SMA Jack (Female) PCB Through Hole Straight Connector, DC-18GHz VSWR1.25	Standard	50	Straight	18	1.25	PCB Connector	SMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
SSMA2I59-1260A/9Q	SSMA Jack (Female) PCB Throught Hole Right Angle Connector, DC-18GHz VSWR1.30	Precision	50	Right Angle	18	1.30	PCB Connector	SSMA	Jack (Female)	Threaded (Screw-lock)	Soldered	None	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Coaxial End
