Key Specifications
Type Design:
Standard
Connection Type:
Between Series
Connector 1 Series:
BNC
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
FME
Connector 2 Gender:
Plug (Male)
Impedance (Ohm):
50
Body Style:
Right Angle
Panel Mount:
None
Connector 1 Connection Method:
Bayonet
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
2.5
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
Description
BNC Plug (Male) to FME Plug (Male) | L-Adapter | Bayonet & Screw-Lock | Brass Body
he ROSNOL ADL-B1E15A/144-14 is a precision L-adapter designed for DC to 2.5 GHz operation with 50 Ω impedance. It ensures stable signal transmission for low-frequency applications and supports secure coupling with bayonet-lock on the BNC side and screw-lock on the FME side. The adapter is rated for ≥500 mating cycles on the BNC side and ≥300 on the FME side, providing reliable mechanical performance.Center contacts are brass with 3 microinch gold plating over an 80 microinch nickel-phosphorus underplating. Bodies and coupling nuts are brass with copper-tin-zinc alloy finish, and insulators are PTFE for thermal stability. Gaskets are silicone rubber for environmental sealing. The operating temperature range spans −65°C to +165°C, ensuring durability under harsh conditions.
ROSNOL’s precision-engineered RF adapters deliver consistent performance and represent a cost-effective alternative to leading European and American brands. All components are manufactured in ISO 9001-certified facilities and comply with RoHS and REACH standards. Customization services for materials, plating, and mechanical design are available to support specialized interconnect needs.
