Key Specifications
Type Design:
Precision
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
50
VSWR, Max:
1.30
Connector Style:
PCB Connector
Connector Series:
2.4mm
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
None
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
2.4mm PCB Connector | Compression Mount | Stainless Steel Body
The ROSNOL Q2L50-1092A/9X is a 2.4mm compression mount jack designed for high-speed CPW, microstrip, or stripline PCB applications. It employs a screw-lock coupling mechanism and supports frequencies up to 50 GHz with a 50Ω impedance. This connector is ideal for precision RF designs requiring minimal signal loss and high isolation.It is built with a gold-plated beryllium copper center contact and a passivated stainless steel body. The insulator is made of PEI, ensuring thermal stability and dielectric performance.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
