Key Specifications
Type Design:
Precision
Impedance (Ohm):
50
Body Style:
Straight
Frequency, Max (GHz):
40
VSWR, Max:
1.22
Connector Series:
2.92mm
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Crimped
Mount Method:
None
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
2.92mm Compression Mount Connector | Screw‑Lock | Stainless Steel Body
The ROSNOL K2LA50-1092B/9X is a 2.92mm Female compression‑mount connector designed for high‑speed stripline PCB transitions, supporting 50 Ω operation from DC to 40 GHz with VSWR ≤1.22. Its screw‑lock coupling, ≥500 mating cycles, and controlled impedance performance make it suitable for precision RF measurement systems, broadband signal routing, and high‑frequency digital/analog mixed‑signal interfaces.Constructed with a stainless‑steel passivated body, gold‑plated beryllium‑copper center contact, and PEI insulation, the connector ensures excellent conductivity, corrosion resistance, and long‑term RF stability. Typical engineering uses include stripline test coupons, high‑speed digital interconnect platforms, and controlled‑impedance evaluation environments.
ROSNOL delivers high‑quality RF interconnect solutions at competitive pricing, manufactured in ISO 9001‑certified facilities and fully compliant with RoHS and REACH standards. Designed as a cost‑effective alternative to leading European and American brands, our components offer reliable performance and long‑term stability. We also provide flexible customization options for materials, plating, and mechanical design.
