Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-PCT1A25B/933-93	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	Precision TNC	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.25
AD-PCT1A25B/933-93	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	SMA	Jack (Female)	Precision TNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.25
AD-PCT1A25A/9XX-9X	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	SMA	Jack (Female)	Precision TNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-PCT1A25A/9XX-9X	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	Precision TNC	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-PCT1A25A/944-94	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	Precision TNC	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25
AD-PCT1A25A/944-94	Precision TNC Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.25	Precision	Between Series	SMA	Jack (Female)	Precision TNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25
AD-PCN2MD25A/9X-94	Precision Jack (Female) to 4.1/9.5 Jack (Female) Adapter, DC-14GHz VSWR 1.13	Precision	Between Series	Precision N	Jack (Female)	4.1/9.5	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	14	Stainless Steel	Passivated	Brass	Copper-Tin-Zinc Alloy	1.13
AD-PCN2MD25A/9X-94	Precision Jack (Female) to 4.1/9.5 Jack (Female) Adapter, DC-14GHz VSWR 1.13	Precision	Between Series	4.1/9.5	Jack (Female)	Precision N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	14	Brass	Copper-Tin-Zinc Alloy	Stainless Steel	Passivated	1.13
AD-PCN1Q25A/9XX-9X	Precision N Plug (Male) to 2.4mm Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision N	Plug (Male)	2.4mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN1Q25A/9XX-9X	Precision N Plug (Male) to 2.4mm Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	2.4mm	Jack (Female)	Precision N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN2PCT25B/9X-9X	Precision N Jack (Female) to Precision TNC Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision N	Jack (Female)	Precision TNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN2PCT25B/9X-9X	Precision N Jack (Female) to Precision TNC Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision TNC	Jack (Female)	Precision N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN2PCT25B/93-93	Precision N Jack (Female) to Precision TNC Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision N	Jack (Female)	Precision TNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.15
AD-PCN1K25B/9XX-9X	Precision N Plug (Male) to 2.4mm Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision N	Plug (Male)	2.92mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN2PCT25B/93-93	Precision N Jack (Female) to Precision TNC Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	Precision TNC	Jack (Female)	Precision N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.15
AD-PCN1K25B/9XX-9X	Precision N Plug (Male) to 2.4mm Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	2.92mm	Jack (Female)	Precision N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCN1K25A/9XX-9X	Precision N Plug (Male) to 2.4mm Jack (Female) Adapter, DC-18GHz VSWR 1.15	Precision	Between Series	2.92mm	Jack (Female)	Precision N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCA1Q25B/9XX-9X	Precision SMA Plug (Male) to 2.4mm Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	Between Series	2.4mm	Jack (Female)	Precision SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCA1Q25A/9XX-9X	Precision SMA Plug (Male) to 2.4mm Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	Between Series	Precision SMA	Plug (Male)	2.4mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCA1Q25A/9XX-9X	Precision SMA Plug (Male) to 2.4mm Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	Between Series	2.4mm	Jack (Female)	Precision SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCA1K25A/9XX-9X	Precision SMA Plug (Male) to 2.92mm Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	Between Series	Precision SMA	Plug (Male)	2.92mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PCA1K25A/9XX-9X	Precision SMA Plug (Male) to 2.92mm Jack (Female) Adapter, DC-27GHz VSWR 1.15	Precision	Between Series	2.92mm	Jack (Female)	Precision SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-MHFI1A25A/99-91	IPEX I Plug (Male) to SMA Jack (Female) Adapter, DC-6GHz VSWR1.3	Standard	Between Series	IPEX I (MFHI)	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Beryllium Copper	Gold Plating (Nickel underplated)	Brass	Gold Plating (Nickel underplated)	1.30
AD-N1A25A/H33-H3	N Plug (Male) to SMA Jack (Female) Adapter, DC-11GHz VSWR1.2	Standard	Between Series	SMA	Jack (Female)	N	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Nickel	Brass	Nickel	1.20
