Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-B1A25A/111-H1	BNC Plug (Male) to SMA Jack (Female) Adapter, DC-4GHz VSWR1.15	Standard	Between Series	SMA	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-B1A25A/111-H1	BNC Plug (Male) to SMA Jack (Female) Adapter, DC-4GHz VSWR1.15	Standard	Between Series	BNC	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-B1103225A/933-93	BNC Plug (Male) to 10-32 Jack (Female) Adapter, DC-1GHz VSWR 1.25	Standard	Between Series	10-32	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Bayonet	1.0	Brass	Nickel	Brass	Nickel	1.25
AD-B1103225A/933-93	BNC Plug (Male) to 10-32 Jack (Female) Adapter, DC-1GHz VSWR 1.25	Standard	Between Series	BNC	Plug (Male)	10-32	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	1.0	Brass	Nickel	Brass	Nickel	1.25
AD-B110232A/933-93	BNC Plug (Male) to DIN 1.0/2.3 Jack (Female) Adapter, 75Ω DC-2GHz	Standard	Between Series	DIN 1.0/2.3	Jack (Female)	BNC	Plug (Male)	75	Straight	None	Bayonet	Bayonet	2.0	Brass	Nickel	Brass	Nickel	N/A
AD-B110232A/933-93	BNC Plug (Male) to DIN 1.0/2.3 Jack (Female) Adapter, 75Ω DC-2GHz	Standard	Between Series	BNC	Plug (Male)	DIN 1.0/2.3	Jack (Female)	75	Straight	None	Bayonet	Bayonet	2.0	Brass	Nickel	Brass	Nickel	N/A
AD-AQ5A25A/991-91	SMA Snap-on R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	SMA Snap-On	R/P Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Snap-On	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ5A25A/991-91	SMA Snap-on R/P Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA Snap-On	R/P Plug (Male)	SMA	Jack (Female)	50	Straight	None	Snap-On	Threaded (Screw-lock)	18	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ2A25A/9X-9X	SMA Snap-on Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	SMA Snap-On	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Snap-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-AQ2A25A/9X-9X	SMA Snap-on Jack (Female) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA Snap-On	Jack (Female)	SMA	Jack (Female)	50	Straight	None	Snap-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-AQ1A25C/911-91	SMA Snap-on Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	SMA Snap-On	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Snap-On	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ1A25C/911-91	SMA Snap-on Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA Snap-On	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Snap-On	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ1A25B/91X-91	SMA Snap-on Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	SMA Snap-On	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Snap-On	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ1A25B/91X-91	SMA Snap-on Plug (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA Snap-On	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Snap-On	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ1A25A-BH/91X-9X	SMA Snap-on Plug (Male) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	SMA Snap-On	Plug (Male)	50	Straight	Bulkhead	Threaded (Screw-lock)	Snap-On	18	Stainless Steel	Passivated	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-AQ1A25A-BH/91X-9X	SMA Snap-on Plug (Male) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.15	Standard	Between Series	SMA Snap-On	Plug (Male)	SMA	Jack (Female)	50	Straight	Bulkhead	Snap-On	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Passivated	1.15
AD-A7N25A/H4-H4	SMA R/P Jack (Female) to N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Standard	Between Series	N	Jack (Female)	SMA	R/P Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-A7N25A/H4-H4	SMA R/P Jack (Female) to N Jack (Female) Adapter, DC-12GHz VSWR 1.15	Standard	Between Series	SMA	R/P Jack (Female)	N	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	12	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
AD-A7MHFIV25A/91-91	SMA R/P Jack (Female) to MHFIV Jack (Female) Adapter, DC-6GHz VSWR 1.40	Standard	Between Series	IPEX IV (MHFIV)	Jack (Female)	SMA	R/P Jack (Female)	50	Straight	None	Snap-On	Threaded (Screw-lock)	6.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.40
AD-A7MHFIV25A/91-91	SMA R/P Jack (Female) to MHFIV Jack (Female) Adapter, DC-6GHz VSWR 1.40	Standard	Between Series	SMA	R/P Jack (Female)	IPEX IV (MHFIV)	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Snap-On	6.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.40
AD-A7B25A/91-94	SMA R/P Jack (Female) to BNC Jack (Female) Adapter, DC-6GHz VSWR 1.20	Standard	Between Series	BNC	Jack (Female)	SMA	R/P Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A7B25A/91-94	SMA R/P Jack (Female) to BNC Jack (Female) Adapter, DC-6GHz VSWR 1.20	Standard	Between Series	SMA	R/P Jack (Female)	BNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Bayonet	6.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A5T25A/H44-H4	SMA R/P Plug (Male) to TNC Jack (Female) Adapter, DC-11GHz VSWR1.20	Standard	Between Series	TNC	Jack (Female)	SMA	R/P Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A5T25A/H44-H4	SMA R/P Plug (Male) to TNC Jack (Female) Adapter, DC-11GHz VSWR1.20	Standard	Between Series	SMA	R/P Plug (Male)	TNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	11	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
