Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-BA1A25A-PT/9X-9X	BMA Plug (Male) to SMA Jack (Female) 2-Hole Flange Panel Adapter, DC-18GHz VSWR 1.25	Standard	Between Series	BMA	Plug (Male)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25
AD-BA1A25A-PF/91-91	BMA Plug (Male) to SMA Jack (Female) 4-Hole Flange Panel Adapter, DC-22GHz VSWR 1.3	Standard	Between Series	SMA	Jack (Female)	BMA	Plug (Male)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Slide-On	22	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.30
AD-BA1A25A-PF/91-91	BMA Plug (Male) to SMA Jack (Female) 4-Hole Flange Panel Adapter, DC-22GHz VSWR 1.3	Standard	Between Series	BMA	Plug (Male)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Slide-On	Threaded (Screw-lock)	22	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.30
AD-BA1A25A-BH/9X-9X	BMA Plug (Male) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.14	Standard	Between Series	SMA	Jack (Female)	BMA	Plug (Male)	50	Straight	Bulkhead	Threaded (Screw-lock)	Slide-On	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.14
AD-BA1A25A-BH/9X-9X	BMA Plug (Male) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.14	Standard	Between Series	BMA	Plug (Male)	SMA	Jack (Female)	50	Straight	Bulkhead	Slide-On	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.14
AD-BA1A25A/9X-9X	BMA Plug (Male) to SMA Jack (Female) Adapter, DC-22GHz VSWR 1.15	Standard	Between Series	SMA	Jack (Female)	BMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Slide-On	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-BA1A25A/9X-9X	BMA Plug (Male) to SMA Jack (Female) Adapter, DC-22GHz VSWR 1.15	Standard	Between Series	BMA	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Slide-On	Threaded (Screw-lock)	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-BA1A25A/1XX-1X	BMA Plug (Male) to SMA Jack (Female) Adapter, DC-22GHz VSWR 1.3	Standard	Between Series	SMA	Jack (Female)	BMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Slide-On	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30
AD-BA1A25A/1XX-1X	BMA Plug (Male) to SMA Jack (Female) Adapter, DC-22GHz VSWR 1.3	Standard	Between Series	BMA	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Slide-On	Threaded (Screw-lock)	22	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30
AD-B2T25A/H4-H4	BNC Jack (Female) to TNC Jack (Female) Adapter, DC-4GHz VSWR 1.35	Standard	Between Series	TNC	Jack (Female)	BNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35
AD-B2T25A/94-94	BNC Jack (Female) to TNC Jack (Female) Adapter, DC-4GHz VSWR 1.35	Standard	Between Series	TNC	Jack (Female)	BNC	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35
AD-B2T25A/94-94	BNC Jack (Female) to TNC Jack (Female) Adapter, DC-4GHz VSWR 1.35	Standard	Between Series	BNC	Jack (Female)	TNC	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35
AD-B2SV25A/H4-H4	BNC Jack (Female) to SHV Jack (Female) Adapter, DC-300MHz VSWR 1.30	Standard	Between Series	SHV	Jack (Female)	BNC	Jack (Female)	50	Straight	None	Bayonet	Bayonet	300MHz	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.30
AD-B2SV25A/H4-H4	BNC Jack (Female) to SHV Jack (Female) Adapter, DC-300MHz VSWR 1.30	Standard	Between Series	BNC	Jack (Female)	SHV	Jack (Female)	50	Straight	None	Bayonet	Bayonet	300MHz	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.30
AD-B2S25A-BHS_IP68/H5-H5	BNC Jack (Female) to SMB Jack (Female) Bulkhead Mount Adapter With IP-68, DC-4 GHz VSWR1.30	Standard	Between Series	SMB	Jack (Female)	BNC	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Snap-On	Bayonet	4.0	Brass	Black Chromium	Brass	Black Chromium	1.30
AD-B2S25A-BHS_IP68/H5-H5	BNC Jack (Female) to SMB Jack (Female) Bulkhead Mount Adapter With IP-68, DC-4 GHz VSWR1.30	Standard	Between Series	BNC	Jack (Female)	SMB	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Bayonet	Snap-On	4.0	Brass	Black Chromium	Brass	Black Chromium	1.30
AD-B1T25B/H33-H3	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	BNC	Plug (Male)	TNC	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Nickel	Brass	Nickel	1.35
AD-B1T25A/H44-H4	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	TNC	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35
AD-B1T25A/H44-H4	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	BNC	Plug (Male)	TNC	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35
AD-B1T25A/H33-H3	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	TNC	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Nickel	Brass	Nickel	1.35
AD-B1T25A/H33-H3	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	BNC	Plug (Male)	TNC	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Nickel	Brass	Nickel	1.35
AD-B1T25A/944-94	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.2	Standard	Between Series	TNC	Jack (Female)	BNC	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-B1T25A/944-94	BNC Plug (Male) to TNC Jack (Female) Adapter, DC-4.0 GHz VSWR 1.2	Standard	Between Series	BNC	Plug (Male)	TNC	Jack (Female)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-B1T15A/933-933	BNC Plug (Male) to TNC Plug (Male) Adapter, DC-4.0 GHz VSWR 1.35	Standard	Between Series	BNC	Plug (Male)	TNC	Plug (Male)	50	Straight	None	Bayonet	Threaded (Screw-lock)	4.0	Brass	Nickel	Brass	Nickel	1.35
