RF Adapters
View
Select Parameters Above to Display in the Window Below.
| Order No | Product Name | Photo zoom_in | Type Design | Connection Type | Connector 1 Series | Connector 1 Gender | Connector 2 Series | Connector 2 Gender | Connector 3 Series | Connector 3 Gender | Impedance (Ohm) | Body Style | Panel Mount | Connector 1 Connection Method | Connector 2 Connection Method | Connector 3 Connection Method | Frequency, Max (GHz) | Connector 1 Body Material | Connector 1 Body Plating | Connector 2 Body Material | Connector 2 Body Plating | Connector 3 Body Material | Connector 3 Body Plating | VSWR, Max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AD-N1N25A-PF/H44-H4 | N Female to Male 4 Hole Adatper, DC-11 GHz |
|
Standard | In-Series | N | Jack (Female) | N | Plug (Male) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 11 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.15 | |||||
| AD-W1V15A/9XX-9XX | 1.85mm to 1.0mm Male Adapter, DC-67 GHz |
|
Precision | Between Series | 1.85mm | Plug (Male) | 1.0mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 67 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.50 | |||||
| AD-W1V25A/9XX-9X | 1.0mm Male to 1.85mm Female Adapter, 67 GHz |
|
Precision | Between Series | 1.0mm | Plug (Male) | 1.85mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 67 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.50 | |||||
| AD-W1V25A/9XX-9X | 1.85mm Female to 1.0mm Male Adapter, 67 GHz |
|
Precision | Between Series | 1.85mm | Jack (Female) | 1.0mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 67 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.50 | |||||
| AD-W2V25A/9X-9X | 1.0mm to 1.85mm Female Adapter, DC-67 GHz |
|
Precision | Between Series | 1.0mm | Jack (Female) | 1.85mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 67 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.50 | |||||
| AD-W2V25A/9X-9X | 1.85mm to 1.0mm Female Adapter, DC-67 GHz |
|
Precision | Between Series | 1.85mm | Jack (Female) | 1.0mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 67 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.50 | |||||
| LPAD-D1N25A/H44-H4 | 7/16 Male to N Female Low Pin Adapter, 7.5 GHz |
|
Standard | Between Series | 7/16 | Plug (Male) | N | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.20 | |||||
| LPAD-D1N25A/H44-H4 | N Female to 7/16 Male Low Pin Adapter, 7.5 GHz |
|
Standard | Between Series | N | Jack (Female) | 7/16 | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.20 | |||||
| LPAD-N2D25A-BH/H4-H4 | N to 7/16 Female Bulkhead Adapter, DC-7.5 GHz, Low Pin |
|
Standard | Between Series | N | Jack (Female) | 7/16 | Jack (Female) | 50 | Straight | Bulkhead | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.15 | |||||
| LPAD-N2D25A-BH/H4-H4 | 7/16 to N Female Bulkhead Adapter, DC-7.5 GHz, Low Pin |
|
Standard | Between Series | 7/16 | Jack (Female) | N | Jack (Female) | 50 | Straight | Bulkhead | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.15 | |||||
| AD-V1PCA15A/9XX-9XX | 1.85mm to Precision SMA Male Adapter, 27 GHz |
|
Precision | Between Series | 1.85mm | Plug (Male) | Precision SMA | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-V1PCA15A/9XX-9XX | Precision SMA to 1.85mm Male Adapter, 27 GHz |
|
Precision | Between Series | Precision SMA | Plug (Male) | 1.85mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-V1PCA25A/9XX-9X | 1.85mm Male to Precision SMA Female Adapter, 27 GHz |
|
Precision | Between Series | 1.85mm | Plug (Male) | Precision SMA | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-V1PCA25A/9XX-9X | Precision SMA Female to 1.85mm Male Adapter, 27 GHz |
|
Precision | Between Series | Precision SMA | Jack (Female) | 1.85mm | Plug (Male) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-V2PCA25A/9X-9X | 1.85mm to Precision SMA Female Adapter, 27 GHz |
|
Precision | Between Series | 1.85mm | Jack (Female) | Precision SMA | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-V2PCA25A/9X-9X | Precision SMA to 1.85mm Female Adapter, 27 GHz |
|
Precision | Between Series | Precision SMA | Jack (Female) | 1.85mm | Jack (Female) | 50 | Straight | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 27 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| ASL-D1D25A/800-80 | 7/16 Female to Male L Adapter, 7.5 GHz |
|
Standard | In-Series | 7/16 | Jack (Female) | 7/16 | Plug (Male) | 50 | Mitered Right Angle | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Silver | Brass | Silver | 1.25 | |||||
| ASL-D1D25A/800-80 | 7/16 Male to Female L Adapter, 7.5 GHz |
|
Standard | In-Series | 7/16 | Plug (Male) | 7/16 | Jack (Female) | 50 | Mitered Right Angle | None | Threaded (Screw-lock) | Threaded (Screw-lock) | 7.5 | Brass | Silver | Brass | Silver | 1.25 | |||||
| AD-A2A25B-PF-EC/9Q-9Q | SMA Female 4 Hole Panel Adapter, DC-18 GHz |
|
Standard | In-Series | SMA | Jack (Female) | SMA | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 18 | Stainless Steel | Gold Plating (Non-magnetic nickel-phosphorus underplating) | Stainless Steel | Gold Plating (Non-magnetic nickel-phosphorus underplating) | 1.15 | |||||
| AD-A2A25D-PF/91-91 | SMA Female 4 Hole Panel Adapter, DC-18 GHz |
|
Standard | In-Series | SMA | Jack (Female) | SMA | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 18 | Brass | Gold Plating (Non-magnetic nickel-phosphorus underplating) | Brass | Gold Plating (Non-magnetic nickel-phosphorus underplating) | 1.15 | |||||
| AD-A2A25D-PF/9X-9X | SMA Female Adapter, 4 Hole Panel, DC-18 GHz |
|
Standard | In-Series | SMA | Jack (Female) | SMA | Jack (Female) | 50 | Straight | 4 Hole Flange | Threaded (Screw-lock) | Threaded (Screw-lock) | 18 | Stainless Steel | Passivated | Stainless Steel | Passivated | 1.15 | |||||
| AD-B1B25A-PF/H44-H4 | BNC Male to Female 4 Hole Adapter, DC-4 GHz |
|
Standard | In-Series | BNC | Plug (Male) | BNC | Jack (Female) | 50 | Straight | 4 Hole Flange | Bayonet | Bayonet | 4.0 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.20 | |||||
| AD-B2B25A-PF-ISO/H4-H4 | BNC Female 4 Hole Panel Adapter, DC-4 GHz |
|
Standard | In-Series | BNC | Jack (Female) | BNC | Jack (Female) | 50 | Straight | 4 Hole Flange | Bayonet | Bayonet | 4.0 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.50 | |||||
| AD-B1B25A-PF/H44-H4 | BNC Female to Male 4 Hole Adapter, DC-4 GHz |
|
Standard | In-Series | BNC | Jack (Female) | BNC | Plug (Male) | 50 | Straight | 4 Hole Flange | Bayonet | Bayonet | 4.0 | Brass | Copper-Tin-Zinc Alloy | Brass | Copper-Tin-Zinc Alloy | 1.20 |
