RF Adapters - ROSNOL RF / Microwave

Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
AD-V2PCA25A/9X-9X	1.85mm Jack (Female) to Precision SMA Jack (Female) Adapter, DC-27 GHz VSWR 1.15	Precision	Between Series	1.85mm	Jack (Female)	Precision SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-V2PCA25A/9X-9X	1.85mm Jack (Female) to Precision SMA Jack (Female) Adapter, DC-27 GHz VSWR 1.15	Precision	Between Series	Precision SMA	Jack (Female)	1.85mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
ASL-D1D25A/800-80	7/16 Plug (Male) to 7/16 Jack (Female) Miter Right Angle Adapter, DC-7.5GHz VSWR 1.25	Standard	In-Series	7/16	Jack (Female)	7/16	Plug (Male)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	7.5	Brass	Silver	Brass	Silver	1.25
ASL-D1D25A/800-80	7/16 Plug (Male) to 7/16 Jack (Female) Miter Right Angle Adapter, DC-7.5GHz VSWR 1.25	Standard	In-Series	7/16	Plug (Male)	7/16	Jack (Female)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	7.5	Brass	Silver	Brass	Silver	1.25
AD-A2A25B-PF-EC/9Q-9Q	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25D-PF/91-91	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A2A25D-PF/9X-9X	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-B1B25A-PF/H44-H4	BNC Plug (Male) to BNC Jack (Female) 4-Hole Panel Adapter, DC-4 GHz VSWR 1.20	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Bayonet	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-B2B25A-PF-ISO/H4-H4	BNC Jack (Female) to BNC Jack (Female) 4-Hole Panel Adapter, DC-4 GHz VSWR 1.50	Standard	In-Series	BNC	Jack (Female)	BNC	Jack (Female)	50	Straight	4 Hole Flange	Bayonet	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.50
AD-B1B25A-PF/H44-H4	BNC Plug (Male) to BNC Jack (Female) 4-Hole Panel Adapter, DC-4 GHz VSWR 1.20	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Straight	4 Hole Flange	Bayonet	Bayonet	4.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20
AD-A2A25B-PF-EC/9X-9X	SMA Jack (Female) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
ASL-A1A25C/9QQ-9Q	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-S2S25A/11-11	SMB Jack (Female) to SMB Jack (Female) Adapter, DC-4 GHz VSWR 1.35	Standard	In-Series	SMB	Jack (Female)	SMB	Jack (Female)	50	Straight	None	Snap-On	Snap-On	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.35
AD-SA1SA15A/111-111	SSMA Plug (Male) to SSMA Plug (Male) Adapter, DC-18GHz VSWR 1.2	Precision	In-Series	SSMA	Plug (Male)	SSMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A1A25C-PF/911-91	SMA Plug (Male) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25C-PF/911-91	SMA Plug (Male) to SMA Jack (Female) 4-Hole Panel Adapter, DC-18GHz VSWR1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	4 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
ASL-A1A25C/9QQ-9Q	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
ASL-A1A25C/944-94	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
ASL-A1A25C/944-94	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15
ASL-A1A25C/911-91	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.25	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
ASL-A1A25C/911-91	SMA Plug (Male) to SMA Jack (Female) Miter Right Angle Adapter, DC-18 GHz VSWR 1.25	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Mitered Right Angle	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.25
AD-PC1PC25B/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female) Adapter, DC-26.5 GHz VSWR 1.15	Precision	In-Series	3.5mm	Plug (Male)	3.5mm	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PC1PC25B/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female) Adapter, DC-26.5 GHz VSWR 1.15	Precision	In-Series	3.5mm	Jack (Female)	3.5mm	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-PF2PSB25A-BLS18/99-99	SMP Jack (Female) to SMP Jack (Female) Adapter, DC-26.5 GHz VSWR 1.43	Standard	In-Series	SMP	Jack (Female)	SMP	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.43
