Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Body Style	Panel Mount	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max
TVAC-AD-A1A25A/9XX-9X	SMA Pulg (Male) to SMA Jack (Female) Adapter With Venting Hole For TVAC Application, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
TVAC-AD-A1A25A/9XX-9X	SMA Pulg (Male) to SMA Jack (Female) Adapter With Venting Hole For TVAC Application, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A1A25A-PT/911-91	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25A-PT/911-91	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25A-PT/9QQ-9Q	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25A-PT/9QQ-9Q	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Stainless Steel	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.15
AD-A1A25A-PT/9XX-9X	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-A1A25A-PT/9XX-9X	SMA Plug (Male) to SMA Jack (Female) 2-Hole Panel Adapter, DC-18GHz VSWR 1.15	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	2 Hole Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.15
AD-A1A25C/9XX-9X	SMA Pulg (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-S1S15A/911-911	SMB Plug (Male) to SMB Plug (Male) Adapter, DC-4 GHz VSWR 1.35	Standard	In-Series	SMB	Plug (Male)	SMB	Plug (Male)	50	Straight	None	Snap-On	Snap-On	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.35
AD-S1S25A/911-91	SMB Plug (Male) to SMB Jack (Female) Adapter, DC-4 GHz VSWR 1.35	Standard	In-Series	SMB	Plug (Male)	SMB	Jack (Female)	50	Straight	None	Snap-On	Snap-On	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.35
AD-S1S25A/911-91	SMB Plug (Male) to SMB Jack (Female) Adapter, DC-4 GHz VSWR 1.35	Standard	In-Series	SMB	Jack (Female)	SMB	Plug (Male)	50	Straight	None	Snap-On	Snap-On	4.0	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.35
AD-PM2PM25A/99-99	SMPM Jack (Female) to SMPM Jack (Female) Adapter, DC-50GHz VSWR 1.30	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)	50	Straight	None	Snap-On	Snap-On	50	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.30
AD-PM2PM25B/99-99	SMPM Jack (Female) to SMPM Jack (Female) Adapter, DC-65GHz	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)	50	Straight	None	Snap-On	Snap-On	65	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	N/A
AD-PM2PM25C/99-99	SMPM Jack (Female) to SMPM Jack (Female) Adapter, DC-65GHz	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)	50	Straight	None	Snap-On	Snap-On	65	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	N/A
AD-SA2SA25A/91-91	SSMA Jack (Female) to SSMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Precision	In-Series	SSMA	Jack (Female)	SSMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
ADTS-PM2PM25A/99-99	SMPM Jack (Female) to SMPM Jack (Female) Telescopic Adapter, DC-40GHz VSWR 1.4	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)	50	Straight	None	Snap-On	Snap-On	40	Beryllium Copper	Gold Plating (Nickel underplated)	Beryllium Copper	Gold Plating (Nickel underplated)	1.40
AD-PM2PM25A-BL25/99-99	SMPM Jack (Female) to SMPM Jack (Female) Bullet Adapter, DC-28GHz VSWR 1.35	Standard	In-Series	SMPM	Jack (Female)	SMPM	Jack (Female)	50	Straight	None	Snap-On	Snap-On	28	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.35
AD-A2A25E-BH/9X-9X	SMA Jack (Female) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2A25F-BH/91-91	SMA Jack (Female) to SMA Jack (Female) Bulkhead Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead Hexagonal Flange	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A1A25C/9XX-9X	SMA Pulg (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20
AD-A2A25H-BHS/91-91	SMA Jack (Female) to SMA Jack (Female) Bulkhead Mount With Sealing Adapter, DC-18GHz VSWR 1.20	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Straight	Bulkhead	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	1.20
AD-A1A25C/133-13	SMA Pulg (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.20
AD-A1A25C/133-13	SMA Pulg (Male) to SMA Jack (Female) Adapter, DC-18GHz VSWR 1.2	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Straight	None	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.20
