2.4mm Female Bulkhead Adapter, DC-50 GHz

Order No:AD-Q2Q25A-BH/9X-9X
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
In-Series
Connector 1 Series:
2.4mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
2.4mm
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
Bulkhead Hexagonal Flange
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
50
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.20

Description

2.4mm Female to 2.4mm Female Bulkhead Adapter, DC-50 GHz, VSWR ≤ 1.20, 50 Ω Impedance.

ROSNOL AD-Q2Q25A-BH/9X-9X is a 2.4 mm Jack (Female) to 2.4 mm Jack (Female) bulkhead RF adapter engineered for ultra-wideband applications. With 50-ohm impedance, DC to 50 GHz frequency coverage, and VSWR ≤ 1.20, it supports excellent signal integrity for advanced microwave and millimeter-wave systems.

The adapter features gold-plated beryllium copper center contacts and stainless steel bodies with non-magnetic nickel-phosphorus underplating to ensure low insertion loss and reliable electrical performance. PEI insulators provide dimensional stability at high frequencies, while silicone rubber gaskets and passivated stainless steel hardware enhance environmental protection and mechanical durability.

Designed with precision screw-lock coupling, this adapter offers secure mating and outstanding RF performance across a broad frequency range. It is suitable for 5G infrastructure, high-speed communication systems, aerospace electronics, millimeter-wave testing, radar development, and precision laboratory measurement applications up to 50 GHz.
