UHF Male to Male Adapter, DC-300 MHz

Order No:AD-U1U15A/H44-H44
Add Cart

Key Specifications

Type Design:
Standard
Connection Type:
In-Series
Connector 1 Series:
UHF
Connector 1 Gender:
Plug (Male)
Connector 2 Series:
UHF
Connector 2 Gender:
Plug (Male)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
None
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
300MHz
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
N/A

Description

UHF Male to UHF Male Straight Adapter, DC-300 MHz, 50 Ω Impedance.

ROSNOL AD-U1U15A/H44-H44 is a UHF Plug (Male) to UHF Plug (Male) straight RF adapter designed for reliable low-frequency RF interconnection up to 300 MHz. This adapter supports efficient signal transfer in radio communication systems, RF equipment, antenna assemblies, and industrial applications utilizing UHF interfaces.

Constructed with phosphor bronze center contacts and 3 µinch gold plating over 80 µinch non-magnetic nickel-phosphorus underplating, the adapter provides excellent electrical contact stability. The brass body and coupling nut feature copper-tin-zinc alloy plating for improved corrosion resistance, while PTFE insulation ensures dependable dielectric performance. Key electrical characteristics include 2000 V rms test voltage, 750 V rms working voltage, 400 W power handling at 300 MHz, and current capacity up to 10 A DC.

Designed as a UHF male-to-male (plug-to-plug) adapter, the AD-U1U15A/H44-H44 offers secure screw-lock coupling, mating life greater than 500 cycles, and durable RF performance. It is ideal for antenna systems, base station equipment, RF communications, amateur radio installations, and general RF interconnect applications.
