Key Specifications
Type Design:
Standard
Connection Type:
In-Series
Connector 1 Series:
N
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
N
Connector 2 Gender:
Jack (Female)
Body Style:
Straight
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
2.0
Connector 1 Body Material:
Brass
Connector 1 Body Plating:
Copper-Tin-Zinc Alloy
Connector 2 Body Material:
Brass
Connector 2 Body Plating:
Copper-Tin-Zinc Alloy
VSWR, Max:
1.25
Impedance 1(Ohm):
50
Impedance 2(Ohm):
75
Description
N 50 Ω Jack to N 75 Ω Jack Impedance Matching Pad | DC to 2 GHz
The ROSNOL MP-N25N27A-2G/H4-H4 impedance matching pad is designed for impedance conversion between N 50 Ω jack (female) and N 75 Ω jack (female) interfaces. Operating from DC to 2 GHz, the device provides stable RF performance with a VSWR of ≤ 1.15 from DC to 0.5 GHz and ≤ 1.25 from 0.5 GHz to 1 GHz. Insertion loss is specified at ≤ 5.7 dB in both transmission directions. The average power handling capability is rated at 0.7 W at 40 °C, with linear derating to 0 W at 125 °C.The MP-N25N27A-2G/H4-H4 features screw-lock coupling and robust mechanical construction. Center contacts are manufactured from phosphor bronze with gold plating over nickel underplating. Connector bodies and coupling nuts are constructed from brass with copper–tin–zinc alloy plating, while PTFE insulators provide stable dielectric properties for long-term operation.
