Cable Connectors - ROSNOL RF / Microwave

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
BNC2DA50-G316A/H4	BNC Female Bulkhead Cable Connector for RG316, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-316
BNC2DA50-G316A/H3	BNC Female Bulkhead Cable Connector for Belden 7805, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	Belden 7805
BNC2DA50-G316A/H3	BNC Female Bulkhead Cable Connector for RG174, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-174
BNC2DA50-G316A/H3	BNC Female Bulkhead Cable Connector for RG188A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-188A
BNC2DA50-G316A/H3	BNC Female Bulkhead Cable Connector for RG316, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-316
BNC2DA50-G142A/H4	BNC Female Bulkhead Cable Connector for RG400, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-400
BNC2DA50-G142A/H4	BNC Female Bulkhead Cable Connector for RG223, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-223
BNC2DA50-G142A/H4	BNC Female Bulkhead Cable Connector for RG55, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-55
BNC2DA50-G142A/H4	BNC Female Bulkhead Cable Connector for RG142, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-142
BNC2DA50-G142A/H3	BNC Female Bulkhead Cable Connector for RG400, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-400
BNC2DA50-G142A/H3	BNC Female Bulkhead Cable Connector for RG223, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-223
BNC2DA50-G142A/H3	BNC Female Bulkhead Cable Connector for RG55, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-55
BNC2DA50-G142A/H3	BNC Female Bulkhead Cable Connector for RG142, 4 GHz	Standard	50	Straight	4.0	1.15	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	Bulkhead	Brass	Nickel	Mechanical Captivation	RG-142
BNC2D50-G058A/H4	BNC Female Cable Connector for LMR 195, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-195
BNC2D50-G058A/H4	BNC Female Cable Connector for Belden 9907, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 9907
BNC2D50-G058A/H4	BNC Female Cable Connector for Belden 7806A, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 7806A
BNC2D50-G058A/H4	BNC Female Cable Connector for RG 303, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-303
BNC2D50-G058A/H4	BNC Female Cable Connector for RG 141, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-141
BNC2D50-G058A/H4	BNC Female Cable Connector for RG 58C, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58C
BNC2D50-G058A/H4	BNC Female Cable Connector for RG 58A, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58A
BNC2D50-G058A/H4	BNC Female Cable Connector for RG 58, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58
BNC2D50-G058A/H3	BNC Female Cable Connector for LMR 195, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	LMR-195
BNC2D50-G058A/H3	BNC Female Cable Connector for Belden 9907, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	Belden 9907
BNC2D50-G058A/H3	BNC Female Cable Connector for Belden 7806A, 4GHz	Standard	50	Straight	4.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	Belden 7806A
