Cable Connectors - ROSNOL RF / Microwave

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
FME1C50-G223A/14	FME Male Cable Connector for RG55, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-55
FME1C50-G223A/14	FME Male Cable Connector for RG223, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-223
F1C70-EZR600A/144	F Male Cable Connector For LMR600, 1 GHz	Standard	75	Straight	1.0	1.30	F	Plug (Male)	Threaded (Screw-lock)	Plug-in	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-600
F1C70-G011A/133	F Male Cable Connector for RG11, 2 GHz	Standard	75	Straight	2.0	1.30	F	Plug (Male)	Threaded (Screw-lock)	Crimped	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-11
CQ2C50-R300A/H1	C Quick-Fit Female Cable Connector for RNL300, 8GHz	Standard	50	Straight	8.0	N/A	C Quick-Fit	Jack (Female)	Quick Lock	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	ROSNOL RNL-300
CQ2C50-R300A/H1	C Quick-Fit Female Cable Connector for LMR300, 8GHz	Standard	50	Straight	8.0	N/A	C Quick-Fit	Jack (Female)	Quick Lock	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	LMR-300
CQ2C50-R200A/H1	C Quick-Fit Female Cable Connector for RNL200, 8GHz	Standard	50	Straight	8.0	N/A	C Quick-Fit	Jack (Female)	Quick Lock	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	ROSNOL RNL-200
CQ2C50-R200A/H1	C Quick-Fit Female Cable Connector for LMR200, 8GHz	Standard	50	Straight	8.0	N/A	C Quick-Fit	Jack (Female)	Quick Lock	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	LMR-200
C1C50-R240A/133	C Male Cable Connector for RNL240, DC- 3GHz	Standard	50	Straight	3.0	1.30	C	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	ROSNOL RNL-240
C1C50-R240A/133	C Male Cable Connector for LMR240, DC- 3GHz	Standard	50	Straight	3.0	1.30	C	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	LMR-240
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, Belden 1673J, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673J
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, Belden 1673A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673A
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, RG402, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-402
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, RSF141-PVC, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-PVC
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, RSF141-FEP, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-FEP
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, RSF141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Flex .141 (RSF-141)
BNC2EBF50-0141A/H4	BNC Female Cable Connector, 4 Hole, RSR141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, Belden 1673J, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Belden 1673J
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, Belden 1673A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Belden 1673A
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, RG402, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RG-402
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, RSF141-PVC, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RSF-141-PVC
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, RSF141-FEP, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RSF-141-FEP
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, RSF141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Flex .141 (RSF-141)
BNC2EBF50-0141A/H3	BNC Female Cable Connector, 4 Hole, RSR141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
