Cable Connectors - ROSNOL RF / Microwave

Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, Belden 1671J, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Belden 1671J
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, Belden 1671A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Belden 1671A
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, RG405, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RG-405
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, RSF086-PVC, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RSF-086-PVC
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, RSF086-FEP, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RSF-086-FEP
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, RSF086, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Flex .086 (RSF-086)
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, Belden 1671A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Belden 1671A
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RTK-Flex 405, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RTK-Flex 405
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RTK-FS 085, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RTK-FS 085
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RG405, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RG-405
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, UT85, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	UT-85
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RSF085-FEP, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	RSF-085-FEP
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RSF085, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Flex .085 (RSF-085)
BNC2EBF50-0085A/H4	BNC Female Cable Connector, 4 Hole, RSR085, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
BNC2EBF50-0085A/H3	BNC Female Cable Connector, 4 Hole, RSR086, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	4 Hole Flange	Brass	Nickel	Mechanical Captivation	Semi-Rigid .086 (RSR-086)
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, Belden 1673J, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673J
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, Belden 1673A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 1673A
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, RG402, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-402
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, RSF141-PVC, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-PVC
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, RSF141-FEP, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RSF-141-FEP
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, RSF141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Flex .141 (RSF-141)
BNC2EA50-0141A/H4	BNC Female Bulkhead Cable Connector, RSR141, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
BNC2EA50-0141A/H3	BNC Female Bulkhead Cable Connector, Belden 1673J, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Belden 1673J
BNC2EA50-0141A/H3	BNC Female Bulkhead Cable Connector, Belden 1673A, 6 GHz	Standard	50	Straight	6.0	1.22	BNC	Jack (Female)	Bayonet	Crimped or Soldered	Soldered	Bulkhead	Brass	Nickel	Mechanical Captivation	Belden 1673A
