Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
K1E50-0141A/91X	2.92mm Male Cable Connector, RSR141, RSF141, 40GHz	Precision	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .141 (RSF-141)
K1E50-0141A/91X	2.92mm Male Cable Connector for .141, 40GHz	Precision	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .141 (RSR-141)
K1E50-0118B/9XX	2.92mm Male Cable Connector for .118, 40GHz	Precision	50	Straight	40	1.25	2.92mm	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Stainless Steel	Passivated	Mechanical Captivation	0.118
K1E50-0085A/999	2.92mm Male Cable Connector for Sucoform 86, 40GHz	Precision	50	Straight	40	1.30	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Beryllium Copper	Gold Plating (Nickel underplated)	Mechanical Captivation	Sucoform 86
K1E50-0085A/999	2.92mm Male Cable Connector for MF85, 40GHz	Precision	50	Straight	40	1.30	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Beryllium Copper	Gold Plating (Nickel underplated)	Mechanical Captivation	MF-085
K1E50-0085A/999	2.92mm Male Cable Connector for RSR085, RSF085, 40GHz	Precision	50	Straight	40	1.30	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Beryllium Copper	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Flex .085 (RSF-085)
K1E50-0085A/999	2.92mm Male Cable Connector for .085, 40GHz	Precision	50	Straight	40	1.30	2.92mm	Plug (Male)	Threaded (Screw-lock)	Plug-in	Soldered	None	Beryllium Copper	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
K1E50-0047A/999	2.92mm Male Cable Connector for RSF047-FEP, 40GHz	Standard	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .047 (RSF-047)
K1E50-0047A/999	2.92mm Male Cable Connector for RSF047-PVC, 40GHz	Standard	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .047 (RSF-047)
K1E50-0047A/999	2.92mm Male Cable Connector for RSR047, RSF047, 40GHz	Standard	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .047 (RSF-047)
K1E50-0047A/999	2.92mm Male Cable Connector for .047, DC- 40GHz	Standard	50	Straight	40	1.20	2.92mm	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Beryllium Copper	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .047 (RSF-047)
HPSMP2C59-G316A/94	High Power SMP Female RA Cable Connector for RNL100, 10GHz	Standard	50	Right Angle	10	1.20	High Power SMP	Jack (Female)	Snap-On	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-100
HPSMP2C59-G316A/94	High Power SMP Female RA Cable Connector for LMR100, 10GHz	Standard	50	Right Angle	10	1.20	High Power SMP	Jack (Female)	Snap-On	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-100
HPSMP2C59-G316A/94	High Power SMP Female RA Cable Connector for RG188, 10GHz	Standard	50	Right Angle	10	1.20	High Power SMP	Jack (Female)	Snap-On	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-188
HPSMP2C59-G316A/94	High Power SMP Female RA Cable Connector for RG174, 10GHz	Standard	50	Right Angle	10	1.20	High Power SMP	Jack (Female)	Snap-On	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-174
HPSMP2C59-G316A/94	High Power SMP Female RA Cable Connector for RG316, 10GHz	Standard	50	Right Angle	10	1.20	High Power SMP	Jack (Female)	Snap-On	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-316
HN1C50-R600A/133	HN Male Cable Connector for RNL600, DC- 6GHz	Standard	50	Straight	6.0	N/A	HN	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	ROSNOL RNL-600
HN1C50-R600A/133	HN Male Cable Connector for LMR600, DC- 6GHz	Standard	50	Straight	6.0	N/A	HN	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	LMR-600
FME2C59-G058B/H4	FME Female RA Cable Connector for LMR195, 2.5GHz	Standard	50	Right Angle	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-195
FME2C59-G058B/H4	FME Female RA Cable Connector for RG303, 2.5GHz	Standard	50	Right Angle	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-303
FME2C50-R300A/H4	FME Female Cable Connector for RNL300, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-300
FME2C50-R300A/H4	FME Female Cable Connector for LMR300, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-300
FME2C50-R300A/H3	FME Female Cable Connector for RNL300, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	ROSNOL RNL-300
FME2C50-R300A/H3	FME Female Cable Connector for LMR300, DC- 2.5GHz	Standard	50	Straight	2.5	N/A	FME	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	LMR-300

Cable Connectors
