Key Specifications
Description
N Plug (Male) Straight Cable Connector for LMR 400, DC to 6GHz. VSWR ≤ 1.30, 50 Ω, with clamped cable entry.
The ROSNOL N1D50-R400A/144 N Straight Cable Plug is engineered for 50 Ω impedance systems and supports frequencies from DC to 6 GHz with a maximum VSWR of 1.30 (≥17.69 dB return loss). Featuring a screw-lock coupling mechanism, the connector supports soldered center contact termination and a clamped cable entry for secure mechanical retention and stable RF performance.
Constructed with a brass body and coupling nut plated in Copper-Tin-Zinc alloy, the connector ensures durability and corrosion resistance. The center contact is brass with gold plating over a nickel underlayer for optimal conductivity. The insulator is made of PTFE, and the gasket is silicone rubber. This model is compatible with Times LMR400, ROSNOL RNL400, RG213, and RG214 cables. Crimp ferrule dimensions vary by cable type.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
