Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
SMA1C59-G058A/944	SMA Male RA Cable Connector for LMR195, 3 GHz	Standard	50	Right Angle	3.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-195
SMA1E50-0085A/144	SMA Male Cable Connector for .085, .086, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
SMA1E50-0085A/11X	SMA Male Cable Connector for EF405, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	ROSNOL EF-405
SMA1E50-0085A/11X	SMA Male Cable Connector for RG405, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	RG-405
SMA1E50-0085A/11X	SMA Male Cable Connector for RSR085, RSF085, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Flex .085 (RSF-085)
SMA1E50-0085A/11X	SMA Male Cable Connector for .085, .086, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
NM-SMA1E50-0085A/111	Non-Magnetic SMA Male Connector for RG405, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-405
NM-SMA1E50-0085A/111	Non-Magnetic SMA Male Connector for EF405, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	ROSNOL EF-405
NM-SMA1E50-0085A/111	Non-Magnetic SMA Male Connector for RSR085, RSF085, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Flex .085 (RSF-085)
NM-SMA1E50-0085A/111	Non-Magnetic SMA Male Connector for .085, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
SMA1E50-0085A/111	SMA Male Cable Connector for .085, .086, 18 GHz	Standard	50	Straight	18	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .085 (RSR-085)
TNC2C50-G316A/H3	TNC Female Cable Connector for RG188, 6 GHz	Standard	50	Straight	6.0	N/A	TNC	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-188
SMA1E50-0047A/11X	SMA Male Cable Connector for .047, 26.5 GHz	Standard	50	Straight	26.5	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .047 (RSR-047)
SMA1E50-0047A/111	SMA Male Cable Connector for .047, 26.5 GHz	Standard	50	Straight	26.5	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Soldered	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Semi-Rigid .047 (RSR-047)
SMA1C50-G316A/133	SMA Male Cable Connector for RG316, DC- 6 GHz	Standard	50	Straight	6.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-316
SMA1C50-G316A/11X	SMA Male Cable Connector for RG316, DC- 6 GHz	Standard	50	Straight	6.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-316
SMA2C50-G058A/91	SMA Female Cable Connector for RNL195, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	ROSNOL RNL-195
SMA1C50-G316A/111	SMA Male Cable Connector for RG316, DC- 6 GHz	Standard	50	Straight	6.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-316
SMA2C50-G058A/9X	SMA Female Cable Connector for RNL195, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Stainless Steel	Passivated	Mechanical Captivation	ROSNOL RNL-195
SMA1C50-G142A/133	SMA Male Cable Connector for RG142, DC- 6 GHz	Standard	50	Straight	6.0	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-142
UHF1CN0-G316A/133	UHF Male Cable Connector for Belden 7805, 300 MHz	Standard	Non-Constant	Straight	300MHz	N/A	UHF	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 7805
SMA2E50-0047A/99	SMA Female Cable Connector for RSF047-PVC, 18 GHz	Standard	50	Straight	18	1.20	SMA	Jack (Female)	Threaded (Screw-lock)	Crimped or Soldered	Soldered	None	Beryllium Copper	Gold Plating (Nickel underplated)	Mechanical Captivation	RSF-047-PVC
SMA1E50-0047A/9HH	SMA Male Cable Connector for RSF047-PVC, 26.5 GHz	Standard	50	Straight	26.5	1.20	SMA	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Soldered	None	Phosphor Bronze	Gold Plating (Nickel underplated)	Mechanical Captivation	RSF-047-PVC
SMC1C50-G058A/H11	SMC Male Cable Connector for RNL195, 6 GHz	Standard	50	Straight	6.0	1.22	SMC	Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	ROSNOL RNL-195
