Key Specifications
Description
7/16 Jack (Female) Straight Cable Connector for LMR 400 cable, DC to 6GHz VSWR ≤ 1.30 50Ω, with clamped cable entry.
The ROSNOL 716-2D50-R400A/H4 is a 7/16 Jack (Female) RF connector designed for clamped cable entry and screw-lock coupling. Operating at 50 Ω impedance and supporting frequencies from DC to 6 GHz, it ensures stable signal transmission with a maximum VSWR of 1.30. The connector features a soldered center contact and is compatible with LMR 400, RNL-400, RG-213, and RG-214 cables, making it ideal for high-frequency and high-power RF systems.
This connector is built with a brass body and clamp nut, both plated with Copper-Tin-Zinc alloy for enhanced mechanical strength and corrosion resistance. The center contact is made of phosphor bronze with gold plating over a nickel underplating, ensuring excellent conductivity and long-term durability. The insulator is PTFE, and the gasket is made of silicone rubber, providing robust insulation and environmental sealing.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
