SMA Female Straight Bulkhead Connector, Solder Attachment, Stub Terminal, DC-18 GHz VSWR ≤ 1.25, 50 Ω Impedance.
ROSNOL SMA2FA50-1550A/91 is a 50 Ohm SMA Jack (Female) straight bulkhead connector designed for RF and microwave applications requiring reliable signal transmission from DC to 18 GHz. Featuring a solder attachment with a stub terminal configuration, this connector delivers stable electrical performance with VSWR ≤ 1.25, low insertion loss, and RF leakage of at least 100 dB up to 1 GHz. Additional electrical characteristics include insulation resistance of ≥ 5 GΩ, working voltage of 480 V rms, and power handling capability up to 200 W at 2 GHz, making it suitable for high-frequency interconnect systems.
The connector utilizes a beryllium copper center contact with gold plating over a non-magnetic nickel-phosphorus underplating. The body, fastening nut, and washer are manufactured from brass and finished with the same gold-plated structure, while a PTFE insulator provides excellent dielectric stability. A screw-lock coupling mechanism ensures secure mating, and the connector supports more than 500 mating cycles. The soldered center contact design and operating temperature range of -65°C to +165°C contribute to dependable long-term performance.
This SMA female bulkhead connector is suitable for RF test and measurement equipment, microwave subsystems, wireless communication devices, laboratory instrumentation, antenna systems, and general RF interconnection assemblies. Its broadband DC-18 GHz capability, durable plated construction, and reliable panel-mount design make it a practical solution for engineers seeking stable signal integrity in demanding RF environments.
