Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max	Volt
DB-V1V25A-67G60V/9XX-9X	1.85mm Plug (Male) to 1.85mm Jack (Female), DC-67GHz VSWR1.30 60V	Precision	In-Series	1.85mm	Plug (Male)	1.85mm	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	67	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30	60
DB-V1V25A-67G60V/9XX-9X	1.85mm Plug (Male) to 1.85mm Jack (Female), DC-67GHz VSWR1.30 60V	Precision	In-Series	1.85mm	Jack (Female)	1.85mm	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	67	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30	60
DB-Q1Q25A-50G50V/9XX-9X	2.4mm Plug (Male) to 2.4mm Jack (Female), DC-50GHz VSWR1.30 50V	Precision	In-Series	2.4mm	Plug (Male)	2.4mm	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	50	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30	50
DB-Q1Q25A-50G50V/9XX-9X	2.4mm Plug (Male) to 2.4mm Jack (Female), DC-50GHz VSWR1.30 50V	Precision	In-Series	2.4mm	Jack (Female)	2.4mm	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	50	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30	50
DB-B1B25A-3G50V/H44-H4	BNC Plug (Male) to BNC Jack (Female), DC-3GHz VSWR1.20 50V	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Bayonet	Bayonet	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	50
DB-B1B25A-3G100V/H44-H4	BNC Plug (Male) to BNC Jack (Female), DC-3GHz VSWR1.20 100V	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Bayonet	Bayonet	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	100
DB-B1B25A-3G2KV/H44-H4	BNC Plug (Male) to BNC Jack (Female), DC-3GHz VSWR1.20 2000V	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Bayonet	Bayonet	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	2K
DB-B1B25A-3G100V/9XX-9X	BNC Plug (Male) to BNC Jack (Female), DC-3GHz VSWR1.20 100V	Standard	In-Series	BNC	Plug (Male)	BNC	Jack (Female)	50	Bayonet	Bayonet	3.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20	100
DB-B1B25A-3G100V/9XX-9X	BNC Plug (Male) to BNC Jack (Female), DC-3GHz VSWR1.20 100V	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Bayonet	Bayonet	3.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20	100
DB-B1B25A-1G50V/H44-H4	BNC Plug (Male) to BNC Jack (Female), DC-1GHz VSWR1.20 50V	Standard	In-Series	BNC	Jack (Female)	BNC	Plug (Male)	50	Bayonet	Bayonet	1.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	50
DB-N1N25A-3G100V/H44-H4	N Plug (Male) to N Jack (Female), DC-3GHz VSWR1.20 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	100
DB-N1N25A-3G100V/H44-H4	N Plug (Male) to N Jack (Female), DC-3GHz VSWR1.20 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.20	100
DB-T1T25A-3G100V/944-94	TNC Plug (Male) to TNC Jack (Female), DC-3GHz VSWR1.15 100V	Standard	In-Series	TNC	Jack (Female)	TNC	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	3.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.15	100
DB-PCT1PCT25A-18G100V/H33-H3	Precision TNC Plug (Male) to Precision TNC Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision TNC	Jack (Female)	Precision TNC	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.35	100
DB-PCT1PCT25A-18G100V/H33-H3	Precision TNC Plug (Male) to Precision TNC Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision TNC	Plug (Male)	Precision TNC	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Nickel	Brass	Nickel	1.35	100
DB-V2V25A-67G60V/9X-9X	1.85mm Jack (Female) to 1.85mm Jack (Female), DC-67GHz VSWR1.30 60V	Precision	In-Series	1.85mm	Jack (Female)	1.85mm	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	67	Stainless Steel	Passivated	Stainless Steel	Passivated	1.30	60
DB-N1N25A-6G100V/944-94	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	100
DB-N1N25A-6G100V/944-94	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	100
DB-N1N25A-6G100V/9XX-9X	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25	100
DB-N1N25A-6G100V/9XX-9X	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25	100
DB-N1N25A-6G100V/H44-H4	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	100
DB-N1N25A-6G100V/H44-H4	N Plug (Male) to N Jack (Female), DC-6GHz VSWR1.25 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	6.0	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.25	100
DBIO-A2A25A-18G200V/9X-9X	DC Block on Inner and Outer Conductor SMA Jack (Female) to SMA Jack (Female) Operating From 0.01 to 18 GHz	Standard	In-Series	SMA	Jack (Female)	SMA	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	200
DB-N1N25A-18G100V/9XX-9X	N Plug (Male) to N Jack (Female), DC-18GHz VSWR1.35 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
