Order No	Product Name	Type Design	Connection Type	Connector 1 Series	Connector 1 Gender	Connector 2 Series	Connector 2 Gender	Impedance (Ohm)	Connector 1 Connection Method	Connector 2 Connection Method	Frequency, Max (GHz)	Connector 1 Body Material	Connector 1 Body Plating	Connector 2 Body Material	Connector 2 Body Plating	VSWR, Max	Volt
DB-N1N25A-18G100V/9XX-9X	N Plug (Male) to N Jack (Female), DC-18GHz VSWR1.35 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-N1N25A-18G100V/9XX-9X	N Plug (Male) to N Jack (Female), DC-18GHz VSWR1.35 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-N1N25A-18G100V/944-94	N Plug (Male) to N Jack (Female), DC-18GHz VSWR1.35 100V	Standard	In-Series	N	Plug (Male)	N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35	100
DB-N1N25A-18G100V/944-94	N Plug (Male) to N Jack (Female), DC-18GHz VSWR1.35 100V	Standard	In-Series	N	Jack (Female)	N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Brass	Copper-Tin-Zinc Alloy	Brass	Copper-Tin-Zinc Alloy	1.35	100
DB-PC1PC25A-18G50V/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female), DC-18GHz VSWR1.25 50V	Precision	In-Series	3.5mm	Plug (Male)	3.5mm	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25	50
DB-PC1PC25A-18G50V/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female), DC-18GHz VSWR1.25 50V	Precision	In-Series	3.5mm	Jack (Female)	3.5mm	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.25	50
DB-PC1PC25A-26.5G50V/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female), DC-26.5GHz VSWR1.33 50V	Precision	In-Series	3.5mm	Plug (Male)	3.5mm	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Stainless Steel	Passivated	Stainless Steel	Passivated	1.33	50
DB-PC1PC25A-26.5G50V/9XX-9X	3.5mm Plug (Male) to 3.5mm Jack (Female), DC-26.5GHz VSWR1.33 50V	Precision	In-Series	3.5mm	Jack (Female)	3.5mm	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26.5	Stainless Steel	Passivated	Stainless Steel	Passivated	1.33	50
DB-PCN1PCN25A-18G50V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 50V	Precision	In-Series	Precision N	Plug (Male)	Precision N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	50
DB-PCN1PCN25A-18G50V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 50V	Precision	In-Series	Precision N	Jack (Female)	Precision N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	50
DB-PCN1PCN25A-18G100V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision N	Jack (Female)	Precision N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-PCN1PCN25A-18G100V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision N	Plug (Male)	Precision N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-PCN1PCN25A-18G200V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 200V	Precision	In-Series	Precision N	Plug (Male)	Precision N	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Nickel	1.35	200
DB-PCN1PCN25A-18G200V/9XX-9X	Precision N Plug (Male) to Precision N Jack (Female), DC-18GHz VSWR1.35 200V	Precision	In-Series	Precision N	Jack (Female)	Precision N	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Nickel	1.35	200
DB-PCA1PCA25A-26G100V/9XX-9X	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-26GHz VSWR1.32 100V	Precision	In-Series	Precision SMA	Plug (Male)	Precision SMA	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26	Stainless Steel	Passivated	Stainless Steel	Passivated	1.32	100
DB-PCA1PCA25A-26G100V/9XX-9X	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-26GHz VSWR1.32 100V	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26	Stainless Steel	Passivated	Stainless Steel	Passivated	1.32	100
DB-PCA1PCA25A-26G100V/911-91	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-26GHz VSWR1.32 100V	Precision	In-Series	Precision SMA	Plug (Male)	Precision SMA	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26	Brass	Gold Plating (Nickel underplated)	Brass	Gold Plating (Nickel underplated)	1.32	100
DB-PCA1PCA25A-26G100V/911-91	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-26GHz VSWR1.32 100V	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	26	Brass	Gold Plating (Nickel underplated)	Brass	Gold Plating (Nickel underplated)	1.32	100
DB-PCA1PCA25A-27G50V/9XX-9X	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-27GHz VSWR1.20 50V	Precision	In-Series	Precision SMA	Jack (Female)	Precision SMA	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20	50
DB-PCA1PCA25A-27G50V/9XX-9X	Precision SMA Plug (Male) to Precision SMA Jack (Female), DC-27GHz VSWR1.20 50V	Precision	In-Series	Precision SMA	Plug (Male)	Precision SMA	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	27	Stainless Steel	Passivated	Stainless Steel	Passivated	1.20	50
DB-PCT1PCT25A-18G100V/9XX-9X	Precision TNC Plug (Male) to Precision TNC Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision TNC	Plug (Male)	Precision TNC	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-PCT1PCT25A-18G100V/9XX-9X	Precision TNC Plug (Male) to Precision TNC Jack (Female), DC-18GHz VSWR1.35 100V	Precision	In-Series	Precision TNC	Jack (Female)	Precision TNC	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	18	Stainless Steel	Passivated	Stainless Steel	Passivated	1.35	100
DB-A1A25A-3G16V/H33-H3	SMA Plug (Male) to SMA Jack (Female), DC-3GHz VSWR1.20 16V	Standard	In-Series	SMA	Plug (Male)	SMA	Jack (Female)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	3.0	Brass	Nickel	Brass	Nickel	1.20	16
DB-A1A25A-3G16V/H33-H3	SMA Plug (Male) to SMA Jack (Female), DC-3GHz VSWR1.20 16V	Standard	In-Series	SMA	Jack (Female)	SMA	Plug (Male)	50	Threaded (Screw-lock)	Threaded (Screw-lock)	3.0	Brass	Nickel	Brass	Nickel	1.20	16
