Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
BNC1D50-G058B/133	BNC Male Cable Connector for RG 58, DC- 4GHz	Standard	50	Straight	4.0	1.15	BNC	Plug (Male)	Bayonet	Crimped or Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-58
BNC1D50-G058A/144	BNC Male Cable Connector for RG 400, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-400
BNC1D50-G058A/144	BNC Male Cable Connector for RG 223, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-223
BNC1D50-G058A/144	BNC Male Cable Connector for RG 142, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-142
BNC1D50-G058A/144	BNC Male Cable Connector for RG 58, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58
BNC1D50-G058A/133	BNC Male Cable Connector for LMR195, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	LMR-195
BNC1D50-G058A/133	BNC Male Cable Connector for RG 303, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-303
BNC1D50-G058A/133	BNC Male Cable Connector for RG 400, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-400
BNC1D50-G058A/133	BNC Male Cable Connector for RG 223, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-223
BNC1D50-G058A/133	BNC Male Cable Connector for RG 142, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-142
BNC1D50-G058A/133	BNC Male Cable Connector for RG 141, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-141
BNC1D50-G058A/133	BNC Male Cable Connector for RG 55, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-55
BNC1D50-G058A/133	BNC Male Cable Connector for RG 58, DC- 4GHz	Standard	50	Straight	4.0	1.22	BNC	Plug (Male)	Bayonet	Soldered	Clamped	None	Brass	Nickel	Mechanical Captivation	RG-58
BNC1D50-EZR400A/144	BNC Male Cable Connector for Belden 9913, 4GHz	Standard	50	Straight	4.0	1.25	BNC	Plug (Male)	Threaded (Screw-lock)	Plug-in	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 9913
BNC1D50-EZR400A/144	BNC Male Cable Connector for Belden 7810A, 4GHz	Standard	50	Straight	4.0	1.25	BNC	Plug (Male)	Threaded (Screw-lock)	Plug-in	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 7810A
BNC1D50-EZR400A/144	BNC Male Cable Connector for RNL400, DC- 4GHz	Standard	50	Straight	4.0	1.25	BNC	Plug (Male)	Threaded (Screw-lock)	Plug-in	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-400
BNC1D50-EZR400A/144	BNC Male Cable Connector for LMR400, DC- 4GHz	Standard	50	Straight	4.0	1.25	BNC	Plug (Male)	Threaded (Screw-lock)	Plug-in	Clamped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-400
BNC1C70-MG59A/133	BNC Male Cable Connector for Belden 1855A, 12 GHz	Standard	75	Straight	12	4.42	BNC	Plug (Male)	Bayonet	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 1855A
BNC1C70-G059A/144	BNC Male Cable Connector for RG59B, 1 GHz, 75Ω	Standard	75	Straight	1.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-59
BNC1C70-G059A/133	BNC Male Cable Connector for RG59B, 1 GHz, 75Ω	Standard	75	Straight	1.0	N/A	BNC	Plug (Male)	Bayonet	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	RG-59
BNC1C70-MG59A/133	BNC Male Cable Connector for Mini RG59, 12 GHz	Standard	75	Straight	12	4.42	BNC	Plug (Male)	Bayonet	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	Mini RG-59
BNC1C59-R200A/H33	BNC Male RA Cable Connector for RNL200, 4GHz	Standard	50	Right Angle	4.0	1.20	BNC	Plug (Male)	Bayonet	Soldered	Crimped	None	Brass	Nickel	Mechanical Captivation	ROSNOL RNL-200
BNC2C50-R200A_H3	BNC Female Cable Connector for RNL 200, 4GHz	Standard	50	Straight	4.0	1.20	BNC	Jack (Female)	Bayonet	Plug-in	Crimped	None	Brass	Nickel	Mechanical Captivation	ROSNOL RNL-200
BNC2C50-R200A_H3	BNC Female Cable Connector for Belden 7807A, 4GHz	Standard	50	Straight	4.0	1.20	BNC	Jack (Female)	Bayonet	Plug-in	Crimped	None	Brass	Nickel	Mechanical Captivation	Belden 7807A
